| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 4800 x 1800 x 760 mm | |
|---|---|---|
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Seating capacity | 12 people | |
|---|---|---|
| Static tabletop load capacity | 300 kg | |
| Net product weight | 280 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Edge impact resistance | 10 J | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop substrate | 25mm thick medium-density fiberboard | |
|---|---|---|
| Tabletop surface | 0.6mm thick red walnut wood veneer with high-gloss polyurethane finish | |
| Central channel panel | 8mm thick frosted tempered glass | |
| Pedestal bases | Solid wood frame with MDF infill panels, matching veneer finish | |
| Cable grommets | Brushed stainless steel with plastic flip covers | |
| Integrated control panel | ABS plastic housing with labeled function buttons |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management system | Central recessed channel with 12 evenly spaced grommets for routing power/data cables | |
|---|---|---|
| Modular assembly design | Three-section tabletop joined to three pedestal bases for on-site installation | |
| Integrated equipment control | End-mounted control panel for room AV and power functions | |
| Stable fixed support | Three wide paneled pedestals eliminate wobble during writing or equipment use |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive boardroom | Fits 12-person formal meetings in corporate headquarters or government offices | |
|---|---|---|
| Conference training room | Supports presentation, video conferencing and document review with integrated cable routing |
EU Market Access Requirements* EN Standards
| EN 527-3:2003 | Office tables test methods for stability and mechanical strength | |
|---|---|---|
| EN 13722:2004 | Furniture test for surface resistance to cold liquids for office table tops | |
| EN 312:2010 | Particleboard specifications for structural furniture substrates |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Standard for desk products, applicable to static load and stability testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to tabletop structural performance and finish | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to substrate material formaldehyde limits |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to tabletop structural performance and finish; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable to substrate material formaldehyde limits; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
