Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall assembled dimensions | 3000 x 1220 x 750 mm | |
|---|---|---|
| Tabletop thickness | 40 mm | |
| Tabletop end curvature radius | 610 mm | |
| Under-table knee clearance height | 670 mm | |
| Cable grommet diameter | 80 mm | |
| Panel pedestal base width | 400 mm | |
| Panel pedestal base thickness | 50 mm | |
| Edge profile bevel width | 20 mm | |
| Decorative inlay width at table ends | 15 mm | |
| Seating position clearance per person | 600 mm | |
| Base height from floor to tabletop underside | 670 mm | |
| Grommet spacing along table centerline | 1500 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total product net weight | 136 kg | |
|---|---|---|
| Distributed static tabletop load capacity | 300 kg | |
| Seating capacity | 10 people | |
| Surface abrasion resistance | 2000 cycles | |
| Surface stain resistance rating | Grade 4 | |
| Substrate formaldehyde emission | 0.05 mg/m³ | |
| Leveling glide adjustment range | 15 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop substrate | E1 grade MDF core, density 0.74 g/cm³ | |
|---|---|---|
| Tabletop surface | 0.6 mm cherry wood veneer with multi-coat high-gloss PU finish | |
| Table edge | Solid cherry wood lipping with beveled profile | |
| Pedestal bases | Matching cherry wood veneer over particleboard core, 50mm thick panels | |
| Cable grommets | Brushed metal finished ABS plastic, soft close cover | |
| Foot glides | Nylon base with threaded steel adjustment stem |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management | Two centerline recessed grommets route power/data cables from tabletop to floor | |
|---|---|---|
| Leveling adjustment | Threaded foot glides at base of each pedestal adjust for uneven floors | |
| Surface protection | High-gloss PU topcoat resists scratches, stains and heat from office equipment | |
| Structural support | Three evenly spaced dual-panel pedestal sets eliminate sag on long table span |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Medium to large conference rooms | 10-person capacity supports team meetings, client presentations and board sessions | |
|---|---|---|
| Corporate training and interview spaces | Stable wide surface supports laptops, documents and presentation materials |
EU Market Access Requirements* EN Standards
| EN 527-3:2003 | Office tables test methods for stability and mechanical strength | |
|---|---|---|
| EN 13722:2004 | Furniture test methods for surface finish resistance to abrasion and stains |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety, durability and structural performance |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural performance | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, E1 grade requirement | |
| GB/T 4897.3-2003 | Particleboard specification for furniture use, applicable for base panel cores |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural performance; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, E1 grade requirement; 3. GB/T 4897.3-2003: Particleboard specification for furniture use, applicable for base panel cores; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
