Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 4000 x 1370 x 750 mm | |
|---|---|---|
| Tabletop thickness | 51 mm | |
| Central cable strip dimensions | 3600 x 200 mm | |
| Knee clearance height under table | 670 mm | |
| Support panel height | 670 mm | |
| Support panel thickness | 50 mm | |
| End overhang beyond outer supports | 350 mm | |
| Table edge radius at curved ends | 685 mm | |
| Support panel spacing along length | 1750 mm | |
| Cable access port width at right end | 120 mm | |
| Leveling foot adjustment range | 15 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Evenly distributed static tabletop load capacity | 160 kg | |
|---|---|---|
| Seating capacity (full perimeter) | 12 people | |
| Net product weight | 227 kg | |
| Surface flatness tolerance | 0.006 mm per 1000mm | |
| Edge joint gap maximum | 0.1 mm | |
| Solid wood component moisture content | 12% | |
| Finish abrasion resistance | 1000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop substrate | High-density MDF/particleboard core | |
|---|---|---|
| Tabletop surface | 0.6mm thick AA-grade red hardwood veneer | |
| Surface finish | Multi-coat catalyzed polyurethane lacquer, dust-free sprayed | |
| Support panels | Veneered engineered wood with solid wood edge banding | |
| Central cable strip | Matte light green durable laminate with removable access covers | |
| Hardware | Zinc-plated steel connecting plates and leveling feet |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Central cable management system | Continuous longitudinal channel under center strip for routing power/data cables | |
|---|---|---|
| End power/data integration port | Flush-mounted port at right table end for AC, USB, RJ45 and AV connections | |
| Structure support | Three evenly spaced solid panel bases eliminate cross-braces for unobstructed leg room | |
| Leveling adjustment | Threaded adjustable feet at each support base correct for uneven floors |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Formal corporate boardrooms | Large 12-person capacity supports executive leadership meetings and high-stakes discussions | |
|---|---|---|
| Medium-to-large enterprise meeting rooms | Integrated cable management supports video conferencing and multi-device presentations |
EU Market Access Requirements* EN Standards
| EN 527-3:2003 | Office work tables - test methods for stability and mechanical strength | |
|---|---|---|
| EN 13722:2004 | Furniture - strength, durability and stability requirements for non-domestic seating and tables |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products - Tests for safety, durability and structural adequacy | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture Sustainability Standard |
Standards applicable to China-market projects
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances for wood furniture | |
|---|---|---|
| GB/T 3324-2017 | General technical requirements for wooden furniture |
This product must meet the following technical requirements: 1. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances for wood furniture; 2. GB/T 3324-2017: General technical requirements for wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
