PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions	4800 x 2000 x 760 mm
Finished Top Thickness	45 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Seating capacity	10 people
Static tabletop load capacity	300 kg
Net product weight	320 kg
Surface abrasion resistance	2000 cycles
Edge impact resistance	450 N drop
Top Static Load Reference	150 kg uniformly distributed
Drawer Slide Load / Life	45 kg/pair; 50000 cycles
Hinge Opening Life	Acceptance target 80000 cycles
Top Abrasion Reference	Acceptance target ≥4,000 abrasion cycles or finish-system test
Recommended Procurement Warranty	Structure 5 years; hardware 3 years; finish 2 years

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Tabletop substrate	25mm thick medium-density fiberboard
Tabletop surface	0.6mm thick red walnut wood veneer with high-gloss lacquer
Writing pads	Black matte PVC leatherette inlay
Support structure	Solid wood composite panel base with matching veneer finish
Cable channel lining	Galvanized steel tray with flip-top access
Edge trim	Solid wood matching veneer molding

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Cable management	Central recessed channel with removable covers
Power integration	Pre-cut port at left corner for multi-media, power and network modules
Modular assembly	Bolt-connected sectional panels
Seating access	Open U-shaped inner perimeter

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	2100× 1100× 300 mm
Reference Packaged Gross Weight	90 kg/set in 2 cartons
Reference Packaging Volume	0.55 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Corporate boardrooms	Formal executive meeting space for 10 attendees, matches traditional office decor
Government meeting rooms	Formal wood finish suitable for official conference and briefing spaces

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

No standards data is available for this market.

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

North America procurement and testing reference	Recommended references: ANSI/BIFMA X5.5

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

No standards data is available for this market.

Standardized tender description text

This product must meet the following technical requirements:
1. Technical standards and test reports must be supplied during tender or purchase confirmation;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · CNF-U4800-10P

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · CNF-U4800-10P

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · CNF-U4800-10POpen Export Tool

Quick Actions

Post an RFQ

Product Description

This U-shaped traditional veneer conference table balances formal aesthetic appeal, functional utility, and straightforward installation for professional meeting environments. Its defining U-shaped layout creates an open inner perimeter that allows clear, unobstructed access to each of its 10 seating positions, supporting natural sightlines and collaborative interaction during discussions. The warm red walnut wood grain, finished with a high-gloss lacquer, delivers a classic, polished visual presence aligned with traditional interior design schemes, while integrated black matte PVC leatherette writing pads offer smooth, dedicated writing surfaces at each seat without disrupting the tabletop’s clean, continuous lines. The table is supported by a solid wood composite panel base finished to match the tabletop veneer, with a robust 80mm main support section for structural stability. Its tabletop is constructed from a medium-density fiberboard substrate topped with real wood veneer, edged with solid wood molding for a seamless, refined look, and built to accommodate regular daily use in high-traffic meeting spaces. A centrally positioned recessed cable channel lined with galvanized steel, fitted with removable flip-top covers, runs along the table to keep power, network, and multimedia cords organized and out of sight; a pre-cut port at the left corner is designed to house integrated connectivity modules, eliminating tangled wires across the table surface. The table ships in sectional, bolt-connected panels for straightforward on-site assembly, with generous knee clearance provided for every main seat to support attendee comfort during long meetings. This model is well suited for corporate boardrooms hosting formal executive gatherings, as well as government meeting and briefing rooms where a traditional, professional wood finish aligns with formal space decor. When planning procurement, note that the product ships unbranded across two cartons, with assembly requiring roughly two people to position sections safely given the product’s total net weight, and plan to source compatible power, network, and multimedia modules separately to fit the pre-cut corner port. The fixed U-shaped layout requires adequate open floor space around the table perimeter to allow easy movement for attendees entering and exiting seats.

FurnDim

U-Shaped Traditional Veneer Conference Table with Integrated Power Channel Specifications

CNF-U4800-10P
