Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 6000 x 2000 x 760 mm | |
|---|---|---|
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 800 kg | |
|---|---|---|
| Net weight (assembled) | 450 kg | |
| Surface scratch resistance | 2000 cycles | |
| Structure service life | 10 years | |
| Seating capacity | 10 seats | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop surface | 0.6mm red walnut wood veneer over 25mm MDF substrate, high gloss polyurethane finish | |
|---|---|---|
| Base cabinet | 18mm MDF panel with matching wood veneer finish, solid wood edge banding | |
| Internal framework | 40x40mm square steel tube support frame under desktop | |
| Vent grilles | ABS plastic slotted vents, matte black finish | |
| Edge trim | Solid wood lipping, 2mm thickness, matching veneer finish | |
| Adjustable feet | Nylon base with steel screw thread, 15mm adjustment range |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Integrated cable management | Hidden internal wire channels from each equipment position to central floor access point | |
|---|---|---|
| Ventilated cabinet compartments | Three pairs of vented cabinet doors for equipment heat dissipation | |
| Modular assembly | Three bolt-connected base sections for transport and on-site installation | |
| Equipment mounting compatibility | Pre-drilled mounting points for flush tabletop displays and microphones |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Largest carton dimensions | 2200 x 1100 x 250 mm | |
|---|---|---|
| Total gross shipping weight | 520 kg | |
| Total shipping volume | 1.35 CBM | |
| 40HQ container loading capacity | 18 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Corporate boardrooms | Suits executive meeting spaces requiring 10-person seating and AV integration | |
|---|---|---|
| Government conference facilities | Matches formal traditional wood finish requirements for official meeting rooms |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office furniture - Work tables and desks, safety and strength requirements | |
|---|---|---|
| EN 13722:2004 | Furniture - Strength and durability of storage units for office use |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to dimensional and structural inspection | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to substrate material performance | |
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances for wood furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to dimensional and structural inspection; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable to substrate material performance; 3. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances for wood furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
