Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall assembly footprint | 6000 x 6000 x 750 mm | |
|---|---|---|
| Central round main table diameter | 3000 mm | |
| Curved side wing table depth | 800 mm | |
| Tabletop thickness | 36 mm | |
| Solid wood edge banding thickness | 8 mm | |
| Central recessed cable raceway diameter | 1200 mm | |
| Under-table knee clearance height | 680 mm | |
| Panel leg base width | 300 mm | |
| Per-seat table edge allocation | 700 mm | |
| Side wing segment length per section | 1500 mm | |
| Cable grommet diameter | 83 mm | |
| Floor clearance under table base | 20 mm | |
| Center raceway recess depth | 50 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total seating capacity | 26 seats | |
|---|---|---|
| Uniform distributed tabletop load capacity | 300 kg | |
| Wood component moisture content | 12% | |
| Lacquer finish surface hardness | 2H | |
| Total assembled product weight | 600 kg | |
| Modular connector shear strength | 500 kg | |
| Recommended warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop substrate | E1-grade low-formaldehyde engineered wood panel | |
|---|---|---|
| Surface finish | 0.6mm thick cherry wood veneer with multi-coat polished polyurethane lacquer | |
| Edge treatment | 8mm solid hardwood edge banding with matching finish | |
| Support frame internal structure | 1.5mm thick rectangular steel tubing frame with anti-rust treatment | |
| Leg bases | Veneer-clad engineered wood panel block legs with nylon anti-slip leveling glides | |
| Cable management components | Powder-coated steel cable troughs with removable access covers |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Central cable management system | Recessed circular raceway with pre-cut grommets for power, data and AV cables | |
|---|---|---|
| Modular assembly configuration | Segmented tabletop sections joined with heavy-duty cam-lock connectors for on-site setup | |
| Leveling adjustment | Nylon glides on each leg base to adjust for uneven carpeted or hard flooring | |
| Customizable layout | Curved wing segments can be repositioned or removed to adjust assembly footprint |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| 20ft full container load quantity | 3 sets | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Large corporate boardrooms | Fits 80+ sqm meeting spaces for executive leadership meetings and formal decision-making | |
|---|---|---|
| Government conference facilities | Formal wood finish meets official meeting room furnishing requirements for hosted events |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables and desks, safety and strength requirements for commercial use | |
|---|---|---|
| EN 13722:2004 | Furniture, tables, test methods for stability and mechanical strength |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products, standard for structural durability and load performance of office tables |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to tabletop structural performance | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable to substrate and adhesive emissions | |
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to engineered wood substrate quality |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to tabletop structural performance; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable to substrate and adhesive emissions; 3. GB/T 4897.3-2003: Particleboard for furniture use, applicable to engineered wood substrate quality; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
