Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 4800 x 1620 x 760 mm | |
|---|---|---|
| Tabletop thickness | 50 mm | |
| Central cable channel width | 150 mm | |
| Knee clearance height under table | 680 mm | |
| Knee clearance depth between panel bases | 1200 mm | |
| End panel base width | 400 mm | |
| Middle panel base width | 200 mm | |
| Rounded table edge radius | 80 mm | |
| Surface area per seated attendee | 685 mm width per seat | |
| Right-side cable access port size | 120 x 80 mm | |
| Support base total height | 710 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total static tabletop load capacity | 300 kg | |
|---|---|---|
| Seating capacity | 14 people | |
| Surface abrasion resistance | 2000 cycles | |
| Finish warranty period | 5 years | |
| Net product weight | 250 kg | |
| Panel base static load per support | 100 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop substrate | E1-grade high-density MDF core | |
|---|---|---|
| Tabletop surface | 0.6mm thick red-brown hardwood veneer with multi-coat UV lacquer | |
| Support panel bases | Solid engineered wood panel with matching veneer finish | |
| Central cable channel inlay | Matte light blue tempered glass insert | |
| Edge banding | Solid hardwood edge molding matching veneer color | |
| Underside support structure | Steel reinforced cross beams between panels |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Central cable management | Full-length recessed channel routes power/data cables along table center | |
|---|---|---|
| Cable access port | Right-end port feeds cables from floor to central channel | |
| Leveling adjustment | Hidden adjustable foot pads under panel bases | |
| Modular assembly | Knock-down panel connection for on-site assembly |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Formal executive boardroom use | Suitable for corporate or government meeting spaces for 14attendees | |
|---|---|---|
| AV-enabled meeting configuration | Supports central placement of microphones, video conference units and power outlets |
EU Market Access Requirements* EN Standards
| EN 527-3:2019 | Office furniture tables: test methods for stability and strength | |
|---|---|---|
| EN 13722:2004 | Office furniture: test methods for surface finish durability |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Office tables: performance standard for structural durability |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture | |
|---|---|---|
| GB 18584-2001 | Formaldehyde emission limits for interior wooden furniture | |
| GB/T 4897.3-2003 | Particleboard/MDF specifications for furniture use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture; 2. GB 18584-2001: Formaldehyde emission limits for interior wooden furniture; 3. GB/T 4897.3-2003: Particleboard/MDF specifications for furniture use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
