Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 6000 × 1800 × 760 mm | |
|---|---|---|
| Tabletop thickness | 80 mm | |
| Solid wood edge banding thickness | 8 mm | |
| Central cable channel width | 300 mm | |
| Undertable leg clearance height | 680 mm | |
| Pedestal base quantity | 3 units | |
| Corner radius | 50 mm | |
| End access cutout size | 200 x 150 mm | |
| Base plinth height | 120 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Distributed tabletop static load | 500 kg | |
|---|---|---|
| Paint surface hardness | 2H | |
| Net product weight | 500 kg | |
| Wood component moisture content | 12% | |
| Edge impact resistance | 1000 cycles | |
| Surface abrasion resistance | 2000 cycles | |
| Warranty period | 5 years | |
| Seating capacity (total) | 16 people | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop substrate | 18mm thick E1 grade engineered fiberboard | |
|---|---|---|
| Surface veneer | 0.6mm thick reddish-brown natural wood veneer | |
| Surface finish | High-gloss water-based PU paint | |
| Edge banding | 8mm thick solid hardwood edge sealing | |
| Internal support | Rectangular steel tube frame under tabletop | |
| Base construction | Engineered wood panel with veneer and paint finish, anti-slip nylon feet |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management system | Full-length recessed central trough with removable cover | |
|---|---|---|
| End access ports | Recessed cutouts at both short table ends | |
| Multimedia integration | Reserved mounting space for power, USB, HDMI and conference modules | |
| Assembly structure | Knockdown panel construction with bolted connection joints |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive boardroom | Fits 100+ sqm formal meeting spaces for corporate leadership decision-making | |
|---|---|---|
| Government meeting facility | Meets formal office furniture standards for official conference venues |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office furniture - Work tables and desks, safety and strength requirements reference | |
|---|---|---|
| EN 13722:2004 | Office furniture - Conference tables, performance and dimensional requirements |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to dimensional and finish acceptance | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances of wood based furniture | |
| GB/T 10357.1-2013 | Test of mechanical properties of furniture - strength and durability of tables |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to dimensional and finish acceptance; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances of wood based furniture; 3. GB/T 10357.1-2013: Test of mechanical properties of furniture - strength and durability of tables; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
