Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall assembled dimensions | 2400 x 1200 x 750 mm | |
|---|---|---|
| Tabletop thickness | 40 mm | |
| Under-table knee clearance height | 690 mm | |
| Pedestal support width (each) | 600 mm | |
| Modesty panel height | 400 mm | |
| Cable port cutout diameter | 80 mm | |
| Edge lipping thickness | 3 mm | |
| Dark vertical accent trim width (per pedestal) | 50 mm | |
| End tabletop radius (rounded ends) | 300 mm | |
| Per-person seating space allocation | 600 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total assembled product weight | 125 kg | |
|---|---|---|
| Uniform tabletop static load capacity | 200 kg | |
| Seating capacity | 8 people | |
| Surface abrasion resistance | 2000 cycles | |
| Finish gloss level | 90 GU | |
| Structural warranty | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop substrate | 25 mm thick MDF core | |
|---|---|---|
| Tabletop surface | 0.6 mm cherry wood veneer with high-gloss PU lacquer | |
| Edge detail | Solid cherry wood bullnose lipping | |
| Pedestal supports | 18 mm thick veneered MDF panels with matte black vertical trim | |
| Modesty panel | 18 mm thick veneered MDF matching table finish | |
| Fasteners and hardware | Zinc-plated steel cam-lock and bolt hardware |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management | Dual edge-mounted cable/data ports route wiring from tabletop to floor | |
|---|---|---|
| Floor stabilization | Fixed panel pedestal base with floor glides prevents wobble on level office floors | |
| Seating access | Boat-shaped curved ends provide extra knee room for end-positioned meeting attendees | |
| Modesty coverage | Full-height central modesty panel blocks view of under-table wiring and seated users' legs |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Corporate boardrooms | Fits 8-person executive meeting spaces with formal traditional office decor | |
|---|---|---|
| Executive office meeting areas | Pairs with leather executive guest chairs for private office meeting zones |
EU Market Access Requirements* EN Standards
| EN 527-3:2003 | Applicable to test methods for office desk and table stability and strength | |
|---|---|---|
| EN 13722:2004 | Applicable to furniture strength and durability requirements for office tables | |
| EN 14372:2004 | Applicable to surface resistance to abrasion, stains and heat for office furniture |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applicable to performance requirements for desk and table products for office use | |
|---|---|---|
| ANSI/BIFMA e3-2019e | Applicable to sustainability and material emission evaluation for commercial furniture |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable to general technical requirements for wooden office furniture | |
|---|---|---|
| GB/T 4897.3-2003 | Applicable to particleboard/MDF substrate structural performance requirements | |
| GB 18584-2001 | Applicable to formaldehyde emission limits for interior wooden furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable to general technical requirements for wooden office furniture; 2. GB/T 4897.3-2003: Applicable to particleboard/MDF substrate structural performance requirements; 3. GB 18584-2001: Applicable to formaldehyde emission limits for interior wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
