Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall table dimensions | 3050 x 1220 x 750 mm | |
|---|---|---|
| Tabletop thickness | 51 mm | |
| Under-table knee clearance height | 680 mm | |
| Under-table knee clearance depth at center | 500 mm | |
| Cable grommet diameter | 51 mm | |
| Grommet spacing along table length | 1500 mm | |
| Individual panel base width | 700 mm | |
| Panel base depth | 200 mm | |
| Edge trim overhang | 25 mm | |
| End taper width at rounded ends | 900 mm | |
| Floor clearance under base panels | 20 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Uniform distributed tabletop load capacity | 136 kg | |
|---|---|---|
| Net product weight | 114 kg | |
| Surface scratch resistance rating | 2000 abrasion cycles | |
| Edge impact resistance | 45 N | |
| Surface moisture resistance | Grade 2 | |
| Vertical support static load per base | 45 kg per panel | |
| Product warranty period | 5 years | |
| Seating capacity | 10 people | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop substrate | 25mm MDF core with AA-grade cherry wood veneer face | |
|---|---|---|
| Tabletop finish | Two-coat catalyzed lacquer topcoat | |
| Panel pedestal bases | 38mm thick engineered wood with matching cherry veneer | |
| Edge trim | Solid hardwood beveled edge with matched cherry finish | |
| Cable grommets | Brushed metal insert with plastic flip cover | |
| Leveling glides | Nylon base with 10mm adjustable metal thread |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management system | Dual surface grommets route power/data cables from tabletop to floor | |
|---|---|---|
| Structural support design | Three equidistant panel pedestals eliminate sag across long span | |
| Leveling adjustment | 10mm height adjustment per foot glide to correct uneven floor surfaces | |
| Assembly configuration | Knock-down flat pack assembly with pre-drilled alignment holes |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Number of shipping cartons | 3 cartons | |
|---|---|---|
| Shipping carton dimensions | 1600 x 800 x 120 mm (tabletop halves), 750 x 250 x 400 mm (bases) | |
| Total shipping gross weight | 136 kg | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Formal corporate boardrooms | Seats 10 for executive meetings, board reviews and client presentations | |
|---|---|---|
| Professional office training spaces | Supports distributed materials, laptops and presentation devices for group sessions |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables and meeting tables safety and strength requirements | |
|---|---|---|
| EN 13722:2004 | Furniture seating and tables test methods for surface durability | |
| EN 717-1:2004 | Wood-based panels formaldehyde emission classification by chamber method |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Standard for desk and table products performance and safety | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard for material emissions and durability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture for office use | |
|---|---|---|
| GB/T 4897.3-2015 | Particleboard/MDF requirements for furniture-grade structural panels | |
| GB 18584-2001 | Indoor decoration material limit of formaldehyde emission for wood furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture for office use; 2. GB/T 4897.3-2015: Particleboard/MDF requirements for furniture-grade structural panels; 3. GB 18584-2001: Indoor decoration material limit of formaldehyde emission for wood furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
