Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 2400 x 1200 x 760 mm | |
|---|---|---|
| Table top thickness | 45 mm | |
| Solid wood edge band thickness | 8 mm | |
| Under-table knee clearance height | 680 mm | |
| Pedestal base footprint (single) | 600 x 300 mm | |
| Pedestal plinth height | 100 mm | |
| Cable grommet diameter | 80 mm | |
| Edge power/data module length | 300 mm | |
| Long-side seating clearance per person | 600 mm | |
| End-side seating clearance | 600 mm | |
| Cross support beam height | 250 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Distributed static table top load capacity | 227 kg | |
|---|---|---|
| Paint surface hardness | 3H | |
| Wood substrate moisture content | 12% | |
| Power module electrical rating | 12A/125V AC, 5V/2.1A USB | |
| Product net weight | 180 kg | |
| Seating capacity | 8 persons | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Table top substrate | 25mm high-density fiberboard | |
|---|---|---|
| Surface veneer | 0.6mm red hardwood veneer | |
| Edge treatment | 8mm solid hardwood edge banding | |
| Surface finish | 8-coat cured polyurethane paint (5 base, 3 top) | |
| Pedestal construction | Veneered MDF panel with stepped plinth base | |
| Base feet | Nylon anti-slip leveling glides |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management system | Two 80mm circular cable grommets routed to under-table trough | |
|---|---|---|
| Integrated power module | Edge-mounted strip with 2 AC outlets, 2 USB charging ports, 1 RJ45 Ethernet port | |
| Structural support | Dual end pedestals connected by central cross beam | |
| Leveling adjustment | Height-adjustable glides on each pedestal plinth |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Formal boardroom | Suits executive and government meeting rooms with traditional red wood office decor | |
|---|---|---|
| Medium meeting spaces | Designed for 10person team meetings, presentations, and client negotiations |
EU Market Access Requirements* EN Standards
| EN 527-3:2003 | Office tables test methods for stability and structural strength, applicable for load verification | |
|---|---|---|
| EN 13722:2004 | Office furniture conference tables performance requirements, recommended for commercial use |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Office tables performance standard, recommended for static load and stability testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable for dimensional and structural acceptance | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, ENF grade emission requirement recommended | |
| GB/T 4893.1-2005 | Surface paint film abrasion resistance test method, ≥2000 revolutions resistance recommended |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable for dimensional and structural acceptance; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, ENF grade emission requirement recommended; 3. GB/T 4893.1-2005: Surface paint film abrasion resistance test method, ≥2000 revolutions resistance recommended; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
