Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 5200 x 1600 x 760 mm | |
|---|---|---|
| Tabletop thickness | 50 mm | |
| Knee clearance height under table | 680 mm | |
| Central cable channel width | 150 mm | |
| Central cable channel depth | 30 mm | |
| Corner support column width | 220 mm | |
| Base panel height | 650 mm | |
| Rounded tabletop edge radius | 30 mm | |
| Embedded power module length | 120 mm | |
| Place setting pad size | 150 x 100 mm | |
| Overhang from base to table edge | 80 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total static tabletop load capacity | 272 kg | |
|---|---|---|
| Seating capacity | 16 people | |
| Finish abrasion resistance | 1000 cycles | |
| Finish water repellency rating | Level B | |
| Structural wobble load tolerance | 150 kg lateral force | |
| Power module port count | 2 AC outlets, 2 USB ports, 2 RJ45 network ports | |
| Seating capacity per long side | 8 people | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop surface | High-gloss polished red walnut wood veneer | |
|---|---|---|
| Tabletop substrate | High-density MDF core | |
| Base structure | Solid carved hardwood with reinforced joinery | |
| Surface finish | UV-cured scratch-resistant clear lacquer | |
| Cable channel liner | PVC plastic track | |
| Corner support caps | Carved solid wood trim |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management | Full-length recessed central channel routes cords along table length | |
|---|---|---|
| Power/data access | Embedded end-mounted power module provides AC, USB and network connectivity | |
| Fixed height design | Non-adjustable 760mm working height optimized for seated meeting use | |
| Modular assembly | Knock-down panel construction for on-site installation |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Primary application space | Corporate executive boardrooms and formal large meeting rooms | |
|---|---|---|
| Recommended configuration | Paired with matching high-back executive leather conference chairs |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2019 | Office work tables safety and strength requirements, applicable for commercial meeting table use | |
|---|---|---|
| EN 13722:2004 | Furniture assessment of surface resistance to wear, applicable to tabletop lacquer finish |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Standard for desk products, covering strength, durability and stability for conference tables |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to formal office wooden conference tables | |
|---|---|---|
| GB/T 4897-2015 | Particleboard/medium density fiberboard standards, applicable to table substrate material | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for indoor office furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to formal office wooden conference tables; 2. GB/T 4897-2015: Particleboard/medium density fiberboard standards, applicable to table substrate material; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for indoor office furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
