Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 4800 x 1800 x 760 mm | |
|---|---|---|
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total seating capacity | 10 persons | |
|---|---|---|
| Tabletop static load capacity | 800 kg | |
| Product net weight | 380 kg | |
| Recommended even distributed load | 500 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Seating capacity per long side | 8 | |
| Seating capacity per short end | 1 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop substrate | 18mm thick MDF core with 0.6mm walnut wood veneer | |
|---|---|---|
| Table edge banding | Solid hardwood edge with polished varnish finish | |
| Pedestal bases | Solid wood frame with veneer cladding, matte dark laminate decorative inserts | |
| Central cable trough cover | 10mm thick frosted tempered glass | |
| Under-frame support structure | 2mm thick steel rectangular tube internal framing | |
| Surface finish | UV-cured clear varnish, semi-gloss sheen |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Central cable management system | Recessed trough under glass cover with pre-drilled cable ports for power and data routing | |
|---|---|---|
| Modesty panel design | Full-length side panels to block leg visibility across the table | |
| Assembly structure | Knock-down construction with bolted connections between base sections and tabletop | |
| Surface leveling | Adjustable glide feet on each pedestal base for uneven floor adjustment |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Total shipping gross weight | 430 kg | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
