Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 3800 × 1600 × 760 mm | |
|---|---|---|
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| distributed tabletop static load | 150 kg | |
|---|---|---|
| seating capacity | 10 people | |
| coating surface hardness | 2H | |
| substrate formaldehyde emission | 0.05 mg/m³ | |
| TVOC emission | 0.1 mg/m³ | |
| wood substrate moisture content | 12% | |
| adjustable glide load rating per foot | 80 kg | |
| commercial product warranty | 5 years | |
| seating capacity per long side | 5 people | |
| Top Static Load Reference | 150 kg uniformly distributed |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| tabletop substrate | E1-grade high-density fiberboard | |
|---|---|---|
| tabletop surface | Natural wood veneer with high-gloss polyurethane lacquer | |
| edge banding | Solid hardwood edge trim | |
| support structure | Engineered wood panel pedestals with solid wood reinforcement | |
| cable raceway cover | Matching wood veneer with brushed metal fasteners | |
| base feet | Nylon anti-slip adjustable glides |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| central cable management | Full-length recessed raceway with removable covers | |
|---|---|---|
| under-table open storage | Modular open cubbies along both long sides | |
| leveling adjustment | Adjustable base glides compensate for uneven floor surfaces | |
| knockdown assembly | Flat-packed panel assembly with cam-lock connectors |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| application space 1 | Corporate boardrooms and executive conference rooms | |
|---|---|---|
| application space 2 | Government and institutional meeting facilities |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 527-3:2003 | Office tables test methods for stability and mechanical strength, recommended for structural validation | |
|---|---|---|
| EN 13722:2004 | Furniture assessment of surface resistance to cold liquids, applicable to lacquer finish testing |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety and durability, applicable to load and stability testing | |
|---|---|---|
| ANSI/BIFMA e3-2019e | Furniture sustainability standard, recommended for material and emissions compliance |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to dimensional and structural inspection | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, required for indoor office air quality compliance | |
| GB/T 4897.3-2003 | Particleboard specification for furniture use, applicable to substrate performance verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to dimensional and structural inspection; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, required for indoor office air quality compliance; 3. GB/T 4897.3-2003: Particleboard specification for furniture use, applicable to substrate performance verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
