| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 4800 x 1800 x 760 mm | |
|---|---|---|
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Seating capacity | 10 persons | |
|---|---|---|
| Tabletop static load capacity | 300 kg | |
| Net weight | 380 kg | |
| Desktop surface abrasion resistance | 2000 cycles | |
| Structural static load factor | 1.5 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop surface | 0.6mm natural cherry wood veneer with high-gloss polyurethane finish | |
|---|---|---|
| Tabletop substrate | 18mm E1 grade MDF board | |
| Support frame and legs | Solid rubberwood with matching veneer wrap | |
| Central cable raceway cover | Matte black PVC panel | |
| Edge banding | 2mm solid wood edge trim with rounded profile | |
| Connection hardware | Zinc-plated steel cam lock and bolt fasteners |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Integrated cable management | Full-length central recessed raceway with 10 pre-cut cable access ports | |
|---|---|---|
| Modular assembly | Two-section panel connection at table midpoint | |
| Rounded edge protection | Rounded bullnose edge profile on all table perimeters | |
| Stable fixed support | Three-point panel leg support structure |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Corporate boardrooms | Serves 10-person executive meetings with integrated cable access for presentation devices | |
|---|---|---|
| Large training rooms | Supports group discussion and training sessions with sufficient per-person workspace |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables and desks - Part 1: Dimensions, applicable for ergonomic clearance verification | |
|---|---|---|
| EN 15372:2016 | Furniture - Strength, durability and safety - Requirements for non-domestic tables, applicable for structural performance testing |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and structural inspection | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances of wooden furniture, applicable for formaldehyde emission testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and structural inspection; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances of wooden furniture, applicable for formaldehyde emission testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
