| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 1200 x 400 x 760 mm | |
|---|---|---|
| Tabletop thickness | 25 mm | |
| Rear raised ledge height | 30 mm | |
| Front modesty panel height | 410 mm | |
| Knee clearance height | 620 mm | |
| Knee clearance width | 1000 mm | |
| Rear lower shelf depth | 250 mm | |
| Rear shelf compartment count | 2 units | |
| End support panel thickness | 25 mm | |
| Rear shelf height from floor | 500 mm | |
| AV control panel width | 120 mm | |
| Floor clearance under end panels | 50 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Tabletop static load capacity | 150 kg | |
|---|---|---|
| Product net weight | 23 kg | |
| Surface wear resistance | 2000 cycles | |
| Surface stain resistance grade | Grade 1 | |
| Recommended user capacity | 1 person | |
| Structural warranty period | 10 years | |
| Leveling adjustment range | 10 mm | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop substrate | 25mm E1 grade MDF core with 0.6mm natural wood veneer layer | |
|---|---|---|
| Surface finish | High-temperature cured polyurethane paint, semi-gloss red brown tone | |
| End support panels | 25mm engineered wood with matching veneer and paint finish | |
| Front modesty panel | 18mm engineered wood with matching veneer, fully framed to tabletop and end panels | |
| Rear storage shelf | 18mm engineered wood with matching veneer, central divider splits into two compartments | |
| Edge banding | 2mm solid wood edge trim matching veneer color, rounded safety edge profile |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Integrated AV control panel | Flush-mounted button module on front top corner for connected AV device operation | |
|---|---|---|
| Cable management routing | Hidden channel under tabletop routes cables from AV panel to floor outlet | |
| Rear open storage | Dual-compartment open shelf under rear worktop for training materials and personal items | |
| Fixed height configuration | Non-adjustable 760mm work surface height aligned with standard office chair seated height |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Corporate training rooms | Fixed installed rows of desks for attendee seating with integrated AV controls for presentation systems | |
|---|---|---|
| Conference room side tables | Auxiliary fixed tables for note-taking and material placement in large meeting spaces |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables and desks, safety and strength requirements for commercial office furniture | |
|---|---|---|
| EN 527-2:2016 | Office work tables, safety, strength and durability requirements for fixed-height desks | |
| EN 13986:2004 | Wood-based panels for structural use, performance requirements for MDF/particleboard substrates |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, applicable for static load and stability performance testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and structural quality checks | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material formaldehyde emission limit for wooden furniture, mandatory for indoor office use | |
| GB/T 4893.4-2013 | Surface wear resistance test method for furniture surfaces, applicable to painted finish acceptance | |
| GB/T 4893.7-2013 | Surface stain resistance test method for furniture, applicable to painted tabletop finish verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and structural quality checks; 2. GB 18584-2001: Indoor decoration material formaldehyde emission limit for wooden furniture, mandatory for indoor office use; 3. GB/T 4893.4-2013: Surface wear resistance test method for furniture surfaces, applicable to painted finish acceptance; 4. GB/T 4893.7-2013: Surface stain resistance test method for furniture, applicable to painted tabletop finish verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
