Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 2400 x 700 x 760 mm | |
|---|---|---|
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Tabletop static load capacity | 300 kg | |
|---|---|---|
| Paint film hardness | 2H | |
| Paint abrasion resistance grade | Grade 3 | |
| Wood substrate moisture content | 12% | |
| Wood veneer thickness | 0.6 mm | |
| Warranty period | 10 years | |
| Formaldehyde emission limit | 5 mg/100g | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Structural substrate | E1 grade high-density MDF, density ≥880kg/m³, anti-corrosion and insect treated | |
|---|---|---|
| Surface veneer | 0.6mm thick natural red walnut wood veneer, consistent grain, no visible defects | |
| Edge banding | Solid wood matching veneer species, tightly bonded with no visible gaps | |
| Paint finish | 7-coat matte polyester eco-friendly paint (4 primer + 3 topcoat), scratch resistant | |
| Hardware fittings | Anti-corrosion zinc-plated steel connectors, tight tolerance joints, no exposed fasteners | |
| Cable grommets | Brushed ABS plastic grommets with removable caps for cable access |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management system | Three evenly spaced tabletop grommets with under-table cable trough for microphone/AV wiring | |
|---|---|---|
| AV control interface | Integrated front-mounted control button strip for courtroom audio/visual system adjustment | |
| Surface retention feature | Full-length raised rear lip on tabletop to prevent documents and devices from sliding off | |
| Leveling adjustment | Concealed adjustable feet at base to compensate for uneven courtroom flooring |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Standard courtroom installation | Fixed placement on elevated dais for 3 seated judicial officers in formal court proceedings | |
|---|---|---|
| Government hearing room use | Suitable for formal administrative hearings, arbitration rooms and official government meeting spaces |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture strength, durability and safety requirements for non-domestic seating and tables | |
|---|---|---|
| EN 13722:2004 | Furniture test methods for assessment of surface resistance to cold liquids |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Performance standard for desk products, covers static load and durability testing |
|---|
Standards applicable to China-market projects
| GB 18581-2020 | Applicable to indoor polyurethane wood furniture paint, limits harmful volatile organic compounds | |
|---|---|---|
| GB/T 3324-2017 | General technical requirements for wooden furniture, covers structural strength and dimensional tolerance | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels used in interior decoration materials | |
| GB/T 4893.4-2013 | Test method for surface wear resistance of furniture coatings |
This product must meet the following technical requirements: 1. GB 18581-2020: Applicable to indoor polyurethane wood furniture paint, limits harmful volatile organic compounds; 2. GB/T 3324-2017: General technical requirements for wooden furniture, covers structural strength and dimensional tolerance; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels used in interior decoration materials; 4. GB/T 4893.4-2013: Test method for surface wear resistance of furniture coatings; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
