Mahogany Finish Panel-End Executive Office Desk with Full Modesty Panel (model EXD-MAH-760DP) is listed under Traditional Dais Table, with overall dimensions of 1829 × 914 × 768 mm and main material of MDF. Load capacity: 136 kg. Certifications: Traditional,commercial,style,panel-end,construction,fixed-height,front,modesty,panel. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 1829 x 914 x 768 mm | |
|---|---|---|
| Tabletop thickness | 32 mm | |
| Vertical end panel thickness | 19 mm | |
| Front modesty panel thickness | 19 mm | |
| Knee clearance height | 622 mm | |
| Knee clearance width | 1220 mm | |
| Under-desk knee clearance depth | 600 mm | |
| Edge banding thickness | 3 mm | |
| Cable grommet diameter | 76 mm | |
| Leveling glide adjustment height | 12 mm | |
| Desktop overhang at front edge | 25 mm | |
| End support leg footprint width | 100 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 136 kg | |
|---|---|---|
| Product net weight | 154 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Edge impact resistance rating | 45 N | |
| Recommended user weight capacity | 136 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop core | 45 lb density engineered flakeboard core | |
|---|---|---|
| Surface finish | Thermally fused mahogany laminate | |
| Edge trim | 3mm PVC matching mahogany edge banding | |
| Structural brackets | 1.5mm thick powder-coated steel | |
| Modesty/end panels | 19mm thick engineered wood panels | |
| Leveling glides | Nylon base with metal threaded stem |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management | Two 76mm round desk grommets | |
|---|---|---|
| Floor leveling | Four adjustable threaded nylon glides | |
| Privacy screening | Full-height solid front modesty panel | |
| Assembly system | Cam-lock fastener joinery |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Private executive offices | Provides professional traditional aesthetic for individual manager workspaces | |
|---|---|---|
| Open plan workstation areas | Suitable for dedicated senior staff work positions in commercial offices |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements for commercial use | |
|---|---|---|
| EN 13722:2004 | Furniture test methods for table surface and structural durability | |
| EN 12521:2015 | Domestic and contract furniture strength, durability and safety requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for load, durability and stability performance | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard for material emissions and environmental impact |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable for structural safety | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard specification for furniture-grade core material performance | |
| GB 18584-2001 | Limit of harmful substances for wooden furniture indoor air quality |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable for structural safety; 2. GB/T 4897.3-2003: Particleboard specification for furniture-grade core material performance; 3. GB 18584-2001: Limit of harmful substances for wooden furniture indoor air quality; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
