Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 2100 x 600 x 760 mm | |
|---|---|---|
| Desktop thickness | 80 mm | |
| Seated under-desk knee clearance | 600 mm | |
| Per-seat writing pad width | 600 mm | |
| Writing pad depth | 350 mm | |
| Front decorative panel height | 620 mm | |
| Base plinth height | 60 mm | |
| Top edge trim thickness | 40 mm | |
| Single diamond relief panel size | 500 x 300 mm | |
| Control button strip length | 180 mm | |
| Under-desk storage pocket depth | 150 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total static desktop load capacity | 200 kg | |
|---|---|---|
| Desktop surface abrasion resistance | 5000 cycles | |
| Paint film hardness | 3H | |
| Wood substrate moisture content | 12% | |
| Gross product weight | 90 kg | |
| Free replacement warranty period | 8 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Core substrate | 18mm thick high-density fiberboard, density 0.80g/cm³ | |
|---|---|---|
| Surface finish | 0.6mm walnut-toned natural wood veneer with water-based polyurethane paint | |
| Writing surface pads | 2mm thick matte black anti-slip faux leather, segmented into 3 sections | |
| Edge trim | 8mm thick solid hardwood matching veneer tone, molded layered profile | |
| Front decorative panel | Carved raised diamond relief MDF panel with framed edge molding | |
| Foot contact pads | 5mm thick non-slip rubber pads installed at base corners |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Front-edge AV control panel | 7-button embedded strip for microphone, presentation and audio control | |
|---|---|---|
| Integrated cable management | Rear desk cutouts for AV, power and network cable routing | |
| Anti-slip writing surface | Faux leather pads prevent document sliding during formal note-taking | |
| Enclosed front facade | Solid panel blocks under-desk view for formal public-facing event use |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Formal conference halls | Seated 3-person speaker configuration for government or corporate annual meetings | |
|---|---|---|
| Courtroom proceedings | Official bench configuration for multi-judge hearing arrangements |
EU Market Access Requirements* EN Standards
| EN 13722:2004 | Office furniture - desks, safety and strength requirements for commercial institutional use | |
|---|---|---|
| EN 71-3:2019 | Migration of certain elements in surface finishes, applicable for painted wood furniture safety |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, static load and durability acceptance criteria for office work surfaces |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable for dimensional and structuralAcceptance | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, minimum E1 grade requirement for indoor use | |
| GB/T 4893.8-2013 | Surface wear resistance test method for furniture finishes, acceptance criterion for desktop durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable for dimensional and structuralAcceptance; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, minimum E1 grade requirement for indoor use; 3. GB/T 4893.8-2013: Surface wear resistance test method for furniture finishes, acceptance criterion for desktop durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
