Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall assembled dimensions | 1350 x 550 x 2000 mm | |
|---|---|---|
| Upper glass section height | 1100 mm | |
| Lower solid door section height | 900 mm | |
| Adjustable shelf thickness | 25 mm | |
| Carcass panel thickness | 18 mm | |
| Top panel thickness | 25 mm | |
| Tempered glass door thickness | 5 mm | |
| Edge banding thickness | 2 mm | |
| Internal shelf clear spacing (upper section) | 330 mm | |
| Plinth base height | 60 mm | |
| Metal pull handle length | 120 mm | |
| Door hinge opening angle | 110 degrees | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total unit static load capacity | 150 kg | |
|---|---|---|
| Lower cabinet drawer/shelf static load | 30 kg | |
| Hinge cycle durability | 80000 open/close cycles | |
| Door lock cycle durability | 20000 lock/unlock cycles | |
| Finish scratch resistance rating | 2H pencil hardness | |
| Net weight (assembled) | 100 kg | |
| Anti-tip wall anchor kit included | 2 connectors | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Carcass construction | E1-grade high-density particleboard core, 0.8mm natural wood veneer overlay | |
|---|---|---|
| Upper door panels | 5mm clear tempered glass with wood-framed edges | |
| Lower door panels | 18mm wood-veneer covered particleboard with scratch-resistant lacquer finish | |
| Hardware components | Polished chrome-finish zinc alloy pull handles, cam locks with 2 keys per lock | |
| Edge treatment | 2mm PVC edge banding on all exposed panel edges | |
| Back panel | 5mm hardboard (MDF) with finished matching veneer edge |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Upper storage access | Three hinged clear glass doors for visible display of books and decorative items | |
|---|---|---|
| Lower secure storage | Three hinged solid wood-veneer doors with keyed cam locks for concealed document storage | |
| Shelf adjustability | Metal-pin supported adjustable shelves in upper bays to accommodate varying item heights | |
| Door alignment | Adjustable concealed hinges to compensate for floor unevenness and door gap alignment |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office storage | Suitable for placement behind executive desks to store books, documents and display awards | |
|---|---|---|
| Open office document storage | Can be used in administrative areas for organized accessible file and supply storage |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety and performance requirements for domestic and office storage furniture | |
|---|---|---|
| EN 312:2010 | Performance specifications for particleboard used in load-bearing furniture applications |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.9 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural performance testing | |
|---|---|---|
| GB 18584-2001 | Limit of formaldehyde emission for wooden interior decoration materials, required for indoor office use | |
| GB/T 4897.3-2003 | Performance requirements for particleboard used in furniture construction |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural performance testing; 2. GB 18584-2001: Limit of formaldehyde emission for wooden interior decoration materials, required for indoor office use; 3. GB/T 4897.3-2003: Performance requirements for particleboard used in furniture construction; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
