Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 1800 x 400 x 2000 mm | |
|---|---|---|
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Single shelf static load capacity | 30 kg | |
|---|---|---|
| Net product weight | 135 kg | |
| Lock mechanism keyed differs | Yes | |
| Service life reference | 8 years | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Cabinet body and door panels | 18mm E1 grade medium density fiberboard with 0.6mm walnut wood veneer finish | |
|---|---|---|
| Glass door panels | 5mm thick clear tempered float glass | |
| Door and drawer handles | Brushed nickel-plated zinc alloy pull handles | |
| Drawer slides | Three-section full extension cold-rolled steel ball bearing slides | |
| Lock cylinders | Zinc alloy keyed cam locks | |
| Edge banding | 2mm thick matching wood grain PVC edge trim |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Storage zoning | Three distinct zones: left tall closed storage with lower drawers, upper glass display, lower right closed storage | |
|---|---|---|
| Lockable storage | Two independent locking sections for private file and supply storage | |
| Adjustable shelving | Removable, height-adjustable shelves in solid door compartments to accommodate items of varying heights | |
| Display function | Upper glass-fronted compartments for decorative items and frequently referenced materials |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office space | Placed behind executive desks for file storage and decorative display, matching classic wood office furniture suites | |
|---|---|---|
| Manager work area | Used for storing confidential documents, office supplies and reference materials with lockable compartments |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable for structural stability verification | |
|---|---|---|
| EN 12150-1:2015 | Thermally toughened soda lime silicate glass for glass door safety compliance | |
| EN 71-3:2019 | Migration of certain elements, applicable for surface finish safety checks |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Office storage furniture performance standard, applicable for load and durability testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural and finish quality inspection | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable for E1 grade material verification | |
| GB/T 4893.4-2013 | Surface abrasion resistance test for furniture surfaces, applicable for veneer finish durability check |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural and finish quality inspection; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable for E1 grade material verification; 3. GB/T 4893.4-2013: Surface abrasion resistance test for furniture surfaces, applicable for veneer finish durability check; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
