Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall cabinet dimensions | 1350 x 500 x 2000 mm | |
|---|---|---|
| Left full-height solid door section width | 450 mm | |
| Middle and right per-column width | 450 mm each | |
| Upper glass door section height | 1100 mm | |
| Lower solid door storage section height | 750 mm | |
| Plinth base height | 80 mm | |
| Crown molding top trim height | 70 mm | |
| Upper glass compartment shelf spacing | 330 mm | |
| Lower storage compartment internal height | 650 mm | |
| Left column lower drawer front height | 320 mm each | |
| Tempered glass door panel thickness | 5 mm | |
| Carcass panel thickness | 18 mm | |
| Adjustable shelf thickness | 25 mm | |
| Arched door panel raised frame width | 50 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Per adjustable shelf static load capacity | 35 kg | |
|---|---|---|
| Coating film hardness | 2H | |
| Heat resistant surface rating | 100 °C | |
| Cabinet net weight | 120 kg | |
| Formaldehyde emission level | 1.5 mg/L | |
| Door hinge open/close cycle rating | 80000 cycles | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Carcass construction | E1 grade engineered wood core with solid wood veneer finish | |
|---|---|---|
| Door panels | Raised arched solid wood framed panels with matching veneer | |
| Upper display door inserts | Clear tempered safety glass panels | |
| Surface finish | Multi-coat matte polyurethane wood finish | |
| Hardware components | Metal lock cylinders, steel hinges, and shelf support pins | |
| Edge and trim details | Solid wood crown molding and plinth base trim |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Storage configuration | Left column full-height closed storage with two lower drawers, middle/right columns upper open glass display with adjustable shelves, lower lockable solid door closed storage | |
|---|---|---|
| Shelf adjustability | 3 position-adjustable shelves per upper glass compartment, with 32mm hole spacing for height customization | |
| Security lock function | Keyed locks on left full-height door and lower right storage door, securing confidential document storage | |
| Dust protection | Framed tight-seal doors on all compartments to reduce dust accumulation on stored books and items |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office space | Positioned behind executive desk for document storage and decorative display of awards/collectibles | |
|---|---|---|
| Private study or home office | Used for book storage, file organization and display of personal decorative items |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Domestic and kitchen storage units and worktops - safety requirements, applicable to structural stability | |
|---|---|---|
| EN 12521:2015 | Furniture - strength, durability and safety for domestic storage furniture, applicable to performance testing |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.9 Storage Units |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to dimensional and structural acceptance | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of formaldehyde emission for wood-based furniture, applicable to environmental acceptance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to dimensional and structural acceptance; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of formaldehyde emission for wood-based furniture, applicable to environmental acceptance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
