Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 1350 x 420 x 2000 mm | |
|---|---|---|
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total product net weight | 115 kg | |
|---|---|---|
| Per shelf static load capacity | 30 kg | |
| Lower cabinet static load per compartment | 50 kg | |
| Total storage capacity | 0.47 cbm | |
| Recommended wall anchor pull-out resistance | 100 kg | |
| Hinge cycle rating per door | 50000 open/close cycles | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Main cabinet carcase | 18mm thick E1 grade medium density fiberboard with cherry wood veneer finish | |
|---|---|---|
| Glass door panels | 5mm clear tempered glass with arched top edge | |
| Solid door panels | 18mm veneered MDF with recessed raised-panel design and molded trim | |
| Shelves | 18mm thick veneered particleboard with front edge banding | |
| Hardware | Zinc alloy lock cores, steel butt hinges, magnetic door catches | |
| Top and base trim | Solid rubberwood molding with stained cherry finish |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Display storage | Two upper glazed bays with three adjustable shelves each for visible display of books and decor | |
|---|---|---|
| Concealed storage | Two lower solid-door compartments and one full-height right solid-door compartment for private, dust-protected storage | |
| Locking security | Three-point lock on full-height right door secures enclosed storage for confidential documents | |
| Adjustable shelving | Shelves in glazed bays support repositioning to accommodate items of varying heights |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office space | Suitable for placement behind executive desks to store documents, awards and reference materials | |
|---|---|---|
| Conference room storage | Installed along conference room walls to hold meeting materials and decorative display pieces |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety and performance requirements for domestic and office storage furniture, including anti-tip provisions | |
|---|---|---|
| EN 13986:2004+A1:2015 | Wood-based panels for structural use, applicable to carcase and shelf panel performance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Performance standard for office storage units, covering load capacity, durability, and stability | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard, applicable for material emissions and social responsibility requirements |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel and veneer office storage units | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for indoor office furniture compliance | |
| GB/T 4897.3-2003 | Particleboard specification for furniture use, applicable to shelf and carcase panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel and veneer office storage units; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for indoor office furniture compliance; 3. GB/T 4897.3-2003: Particleboard specification for furniture use, applicable to shelf and carcase panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
