| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| overall unit dimensions | 4250 x 430 x 2140 mm | |
|---|---|---|
| left glass-fronted upper cabinet section width | 1200 mm | |
| central open display section width | 2250 mm | |
| right full-height solid door section width | 800 mm | |
| open shelf clear height (book storage level) | 320 mm | |
| open shelf clear height (decor display level) | 400 mm | |
| lower solid cabinet section height | 820 mm | |
| upper storage/display section height | 1320 mm | |
| glass door insert thickness | 5 mm | |
| top/bottom structural panel thickness | 19 mm | |
| side/vertical divider panel thickness | 18 mm | |
| cabinet back panel thickness | 18 mm | |
| edge trim thickness | 3 mm | |
| shelf depth for open/glass compartments | 380 mm | |
| vertical bar pull handle length | 120 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| adjustable shelf static load capacity | 30 kg | |
|---|---|---|
| hinge open/close cycle durability | 80000 cycles | |
| hardware neutral salt spray resistance | 72 hours | |
| surface scratch resistance rating | Grade 2 | |
| surface VOC emission level | 40 g/L | |
| available color options | 4 | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| structural core panels | E0-grade medium density fiberboard | |
|---|---|---|
| surface veneer | 0.8mm natural cherry wood veneer | |
| upper left door panels | Clear tempered glass with solid wood framing | |
| lower/right door panels | Veneered MDF solid panels | |
| edge trim | 3mm dark grey PVC edge banding | |
| hardware components | Brushed silver zinc alloy handles, rust-resistant steel hinges |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| storage configuration | Mixed glass-door display, open stepped shelving and solid-door closed storage | |
|---|---|---|
| shelf adjustability | 2 adjustable shelf positions per glass/closed compartment | |
| door operation | 110-degree swing opening for all hinged doors with soft-close optional | |
| installation type | Floor-standing unit with optional anti-tip wall anchors |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| executive office backdrop | Installed behind executive desks for book storage, award display and file organization | |
|---|---|---|
| boardroom perimeter storage | Placed along boardroom walls to store reference materials and display corporate decor |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Domestic and kitchen storage units and worktops, safety and structural performance requirements | |
|---|---|---|
| EN 16122:2012 | Domestic and non-domestic storage furniture, test methods for strength and durability |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Storage furniture performance standard for commercial office installations, covering load and stability |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to dimensional and structural tolerance verification | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material limit of harmful substances in wooden furniture, for formaldehyde and heavy metal testing | |
| GB/T 4897.3-2003 | Particleboard/fiberboard for furniture use, applicable to MDF core panel performance verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to dimensional and structural tolerance verification; 2. GB 18584-2001: Indoor decoration material limit of harmful substances in wooden furniture, for formaldehyde and heavy metal testing; 3. GB/T 4897.3-2003: Particleboard/fiberboard for furniture use, applicable to MDF core panel performance verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
