| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 1800 x 400 x 2000 mm | |
|---|---|---|
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Single shelf static load capacity | 35 kg | |
|---|---|---|
| Net product weight | 125 kg | |
| Door swing angle | 110 degrees | |
| Recommended service life | 10 years | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Core board | 25mm medium-density fiberboard, E1 grade formaldehyde emission | |
|---|---|---|
| Exterior finish | 0.6mm cherry wood veneer with matte polyurethane clear coat | |
| Upper display doors | 5mm clear tempered glass set in wood frame | |
| Door hardware | Brushed zinc alloy vertical pull handles and keyed cam locks | |
| Adjustable shelves | 25mm veneered MDF with metal shelf support pins | |
| Base plinth | 30mm solid wood stained to match veneer |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Upper display storage | 3 adjustable shelves per glass door bay for books and display items | |
|---|---|---|
| Lower enclosed storage | 1 fixed compartment per lower solid door for concealed document storage | |
| Lockable storage | Keyed cam locks on left solid door and lower door sections | |
| Anti-tip protection | Wall anchor bracket included for secure mounting to prevent tipping |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office application | Positioned behind executive desk for book and document storage, display of decorative items | |
|---|---|---|
| Meeting room application | Used as wall storage for meeting materials, reference documents and display pieces |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.9 Storage Units |
|---|
Standards applicable to China-market projects
| Formaldehyde emission recommendation | GB/T 17657E1 grade ≤0.124mg/m³ for wood-based panels | |
|---|---|---|
| Mechanical stability recommendation | GB/T 10357.5for storage furniture strength and durability | |
| Glass safety recommendation | GB 15763.2for tempered glass used in furniture doors |
This product must meet the following technical requirements: 1. Formaldehyde emission recommendation: GB/T 17657E1 grade ≤0.124mg/m³ for wood-based panels; 2. Mechanical stability recommendation: GB/T 10357.5for storage furniture strength and durability; 3. Glass safety recommendation: GB 15763.2for tempered glass used in furniture doors; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
Export data is generated from the current published product record.
Directly download an English report in metric or imperial units.
Download all product information and parameter modules in English.
English title, specifications, materials, standards and purchasing fields.
Prepare customs description, material, usage, dimensions and declaration elements.
