Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall cabinet dimensions | 900 x 450 x 2050 mm | |
|---|---|---|
| Upper glass door section height | 1388 mm | |
| Lower solid door cabinet height | 662 mm | |
| Upper display shelf count | 3 pieces | |
| Upper shelf vertical spacing | 430 mm | |
| Single door width | 420 mm | |
| Lower cabinet internal shelf height | 580 mm | |
| Carcass panel thickness | 25 mm | |
| Door panel thickness | 25 mm | |
| Metal pull handle length | 120 mm | |
| Base plinth height | 60 mm | |
| Glass panel thickness | 5 mm | |
| Edge banding thickness | 1 mm | |
| Lower cabinet shelf count | 1 piece | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Per shelf static load capacity | 30 kg | |
|---|---|---|
| Door hinge cycle rating | 80000 cycles | |
| Assembled unit net weight | 120 kg | |
| Abrasion resistance of finish | 2000 cycles | |
| Recommended warranty period for wood components | 6 years | |
| Available finish color options | 4 options | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Carcass and door frames | Solid wood substrate with reddish brown wood grain finish | |
|---|---|---|
| Upper door panels | Clear float glass set in wooden frames | |
| Door hardware | Brushed nickel-finish steel bar pulls and concealed steel hinges | |
| Back panel | 5mm thick hardboard backing with matching wood finish | |
| Interior shelves | 25mm thick wood composite matching cabinet finish | |
| Lower door panels | Raised solid wood panels with framed edge detail |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Door operation | Outward-swinging hinged doors with 110-degree opening angle | |
|---|---|---|
| Shelf adjustability | 3 upper shelves with 50mm incremental height adjustment | |
| Safety feature | 2 wall-mounted anti-tip restraint brackets to prevent forward tipping | |
| Base leveling | 4 adjustable floor glides for uneven surface alignment |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Office application | Executive office and file room storage for books, documents and display decor | |
|---|---|---|
| Home application | Home study and living room storage for reading materials and collectibles |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Applicable for safety requirements of domestic and office storage cabinets | |
|---|---|---|
| EN 14073-2:2004 | Applicable for office storage furniture safety specifications |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Applicable for performance testing of office storage cabinets | |
|---|---|---|
| ANSI/BIFMA X5.1-2017 | Applicable for structural durability and stability requirements |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable for general technical requirements of wooden furniture | |
|---|---|---|
| GB 18584-2001 | Applicable for formaldehyde emission limits of wooden interior furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable for general technical requirements of wooden furniture; 2. GB 18584-2001: Applicable for formaldehyde emission limits of wooden interior furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
