Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| overall dimensions | 900 x 420 x 2000 mm | |
|---|---|---|
| left column open shelf count | 3 tiers | |
| open shelf depth | 400 mm | |
| open shelf clearance height | 350 mm | |
| left lower door height | 700 mm | |
| right full-height door width | 450 mm | |
| right full-height door height | 1800 mm | |
| base plinth height | 60 mm | |
| top crown trim height | 40 mm | |
| carcass panel thickness | 25 mm | |
| back panel thickness | 4 mm | |
| door panel thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| unit net weight | 120 kg | |
|---|---|---|
| per shelf static load capacity | 45 kg | |
| hinge open angle | 110 degrees | |
| hinge cycle rating | 80000 cycles | |
| edge band thickness | 3 mm | |
| manufacturer limited warranty | 10 years | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| carcass construction | 25mm engineered wood substrate with red-brown cherry grain thermal fused melamine finish | |
|---|---|---|
| back panel | 4mm plywood with matching wood veneer finish | |
| door panels | Raised arched wood panels with matching finish, framed decorative molding | |
| edge banding | 3mm commercial grade PVC edge banding on all exposed panel edges | |
| lock mechanism | 3-position keyed cylinder lock on right full-height door | |
| base and crown trim | Solid wood matching finish decorative molding |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| lockable storage | 3-position keyed cylinder lock secures right full-height compartment | |
|---|---|---|
| shelf adjustability | 5 adjustable internal shelves with 32mm increment mounting holes | |
| floor leveling | 4 adjustable nylon leveling glides at base corners | |
| anti-tip safety | 2 wall-mounted anti-tip restraint brackets included |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| executive office application | Suitable for placement in executive private offices, providing open display for awards/decor and locked storage for confidential files | |
|---|---|---|
| reception area application | Suitable for reception back-of-house storage, organizing documents and display pieces while maintaining a formal professional aesthetic |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety and strength requirements for domestic and office storage furniture | |
|---|---|---|
| EN 12521:2015 | Strength, durability and stability requirements for office storage furniture |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Performance standard for office storage units, applicable for load and durability testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural and finish quality | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable for engineered wood substrate quality |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural and finish quality; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable for engineered wood substrate quality; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
