Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 3600 x 420 x 2200 mm | |
|---|---|---|
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total unit static load capacity | 360 kg | |
|---|---|---|
| Total enclosed storage volume | 2.0 m³ | |
| Net product weight | 380 kg | |
| Warranty period | 3 years | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Cabinet core panels | 18mm thick medium density fiberboard with walnut wood veneer finish | |
|---|---|---|
| Display door panels | 5mm thick clear tempered glass set in solid wood frames | |
| Hardware pulls and locks | Polished zinc alloy bail pulls with brushed nickel finish, keyed cam locks | |
| Internal shelves | 18mm thick veneered particleboard with edge banding | |
| Back panel | 5mm thick hardboard with matching wood grain laminate | |
| Drawer slides | Cold-rolled steel side-mount 3/4 extension slides |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Storage configuration | 8 closed lower doors, 4 glass upper doors, 2 drawers, 3 open central display shelves | |
|---|---|---|
| Locking system | Keyed locks on outermost full-height solid doors for secure storage | |
| Shelf adjustability | Removable, height-adjustable shelves in glass-enclosed compartments | |
| Assembly structure | Knock-down 3-section modular assembly for transport and on-site installation |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Number of shipping cartons | 3 cartons | |
|---|---|---|
| Shipping carton dimensions (per section) | 1240 x 500 x 2260 mm | |
| Total shipping gross weight | 430 kg | |
| Total shipping volume | 4.2 CBM | |
| On-site assembly time | 180 minutes | |
| 40ft HQ container loading quantity | 16 units |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office spaces | Placed behind executive desks for document storage and decorative display of awards or artifacts | |
|---|---|---|
| Conference room perimeter storage | Installed along conference room walls for reference material storage and curated display items |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety and strength requirements for domestic and kitchen storage furniture | |
|---|---|---|
| EN 12521:2015 | Strength, durability and safety requirements for non-domestic storage furniture |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.9 Storage Units |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for surface finish and structural integrity inspection | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wood furniture, for formaldehyde emission verification | |
| GB/T 4897.3-2003 | Specification for particleboard used in furniture, for core panel quality verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for surface finish and structural integrity inspection; 2. GB 18584-2001: Limit of harmful substances in wood furniture, for formaldehyde emission verification; 3. GB/T 4897.3-2003: Specification for particleboard used in furniture, for core panel quality verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
