Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall unit dimensions | 2400 x 400 x 2000 mm | |
|---|---|---|
| Upper glass door zone height | 1330 mm | |
| Lower solid door zone height | 670 mm | |
| Single compartment width | 800 mm | |
| Plinth base height | 80 mm | |
| Number of adjustable shelves per upper compartment | 2 | |
| Shelf spacing in upper compartment | 400 mm | |
| Glass door panel thickness | 5 mm | |
| Wood panel thickness (shelves/partitions) | 20 mm | |
| Door handle length | 120 mm | |
| Back panel thickness | 9 mm | |
| Edge band thickness | 1 mm | |
| Lower storage compartment internal depth | 360 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Single shelf static load capacity | 30 kg | |
|---|---|---|
| Hinge open/close cycle rating | 80000 cycles | |
| Hinge maximum opening angle | 110 degrees | |
| Finish scratch resistance rating | 2H pencil hardness | |
| Recommended maximum evenly distributed top load | 50 kg | |
| Key lock security level | Keyed alike option available | |
| Anti-tip rated load resistance | 200 N lateral force | |
| Net weight per shipping section | 80 kg | |
| Top surface load edge thickness | 30 mm | |
| Shelf Distributed Load | 30 kg/shelf |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Carcass and door construction | Solid rubber wood frame with E1 grade engineered wood core | |
|---|---|---|
| Upper door panels | 5mm clear tempered glass | |
| Lower door panels | 20mm thick solid wood veneer panel | |
| Hardware components | Polished zinc alloy vertical pull handles and key locks | |
| Surface finish | High-hardness reddish brown polyurethane paint | |
| Shelf components | 20mm thick multi-layer wood board with matching edge banding |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Door operation | Hinged swing doors with soft-close buffer hinges | |
|---|---|---|
| Locking mechanism | Central keyed lock per vertical bay | |
| Shelf adjustability | Shelves repositionable in 32mm increments | |
| Anti-tip safety | Two wall anchor brackets included |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office placement | Positioned against rear wall for document and reference book storage | |
|---|---|---|
| Open office file area use | Used for centralized archival document and form storage |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Domestic and kitchen storage units and worktops safety requirements | |
|---|---|---|
| EN 12521:2015 | Furniture strength, durability and safety for non-domestic storage |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.9 Storage Units |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances | |
| GB/T 4893.4-2013 | Surface paint film adhesion test method |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture; 2. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances; 3. GB/T 4893.4-2013: Surface paint film adhesion test method; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
