Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall unit dimensions | 1800 x 470 x 2235 mm | |
|---|---|---|
| Left upper solid door panel size | 550 x 1480 mm | |
| Single drawer front size (left bay) | 480 x 190 mm | |
| Single upper glass door size | 380 x 1080 mm | |
| Lower solid door size (middle/right bays) | 380 x 680 mm | |
| Adjustable shelf depth (display section) | 400 mm | |
| Adjustable shelf spacing (glass section) | 330 mm | |
| Internal drawer interior depth | 146 mm | |
| Base plinth height | 70 mm | |
| Glass panel thickness | 5 mm | |
| Carcass panel thickness | 18 mm | |
| Back panel thickness | 5 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total product net weight | 133 kg | |
|---|---|---|
| Single adjustable shelf static load capacity | 30 kg | |
| Door hinge cycle rating | 80000 open/close cycles | |
| Drawer slide cycle rating | 50000 open/close cycles | |
| Finish abrasion resistance | 2000 cycles | |
| Recommended maximum uniform top load | 50 kg | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Carcass core material | 18mm E1-grade particleboard core | |
|---|---|---|
| Exterior finish | Reddish-brown cherry wood veneer with clear lacquer | |
| Door panels | Clear float glass for upper doors, veneered engineered wood for lower doors | |
| Hardware components | Brushed nickel metal bar pulls, keyed cam locks, steel hinges | |
| Drawer slides | Side-mounted 3-section ball-bearing steel slides | |
| Edge treatment | 1mm PVC edge banding matching veneer finish |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Locking storage system | Keyed cam locks on left door, middle/right door banks secure all compartments | |
|---|---|---|
| Adjustable shelving | 3 position-adjustable shelves per glass display bay for flexible storage height | |
| Door operation | Standard 110-degree opening concealed hinges on all solid and glass doors | |
| Anti-tip safety | 2 wall anchor straps to secure tall cabinet to wall and prevent tipover |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office storage | Suitable for private executive offices to store documents, awards and reference materials | |
|---|---|---|
| Open office filing zone | Usable in shared office document storage areas for locked file and supply storage |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable for structural stability | |
|---|---|---|
| EN 14749:2016 | Domestic/kitchen storage furniture safety, applicable for glass and hardware performance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Storage furniture performance standard for commercial office use | |
|---|---|---|
| ANSI/BIFMA X5.1-2017 | General office furniture safety and durability test requirements |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and finish acceptance | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, E1 grade required for indoor office use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and finish acceptance; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, E1 grade required for indoor office use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
