Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall unit dimensions | 900 x 450 x 2200 mm | |
|---|---|---|
| Left column width | 450 mm | |
| Right column width | 450 mm | |
| Left full-height door internal storage height | 1900 mm | |
| Upper right open shelf compartment height | 380 mm | |
| Middle right open shelf compartment height | 520 mm | |
| Lower right open shelf compartment height | 380 mm | |
| Lower right door internal storage height | 620 mm | |
| Open shelf usable depth | 370 mm | |
| Carcass panel thickness | 25 mm | |
| Back panel thickness | 9 mm | |
| Door panel thickness | 25 mm | |
| Shelf panel thickness | 25 mm | |
| Base plinth height | 100 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Gross unit weight | 95 kg | |
|---|---|---|
| Static load per open shelf | 30 kg | |
| Static load per enclosed storage shelf | 40 kg | |
| Total unit static load capacity | 260 kg | |
| Hinge open angle | 110 degrees | |
| Hinge cycle rating | 80000 cycles | |
| Surface abrasion resistance | 2000 cycles | |
| Anti-tip wall anchor requirement | 2 anchors | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Carcass structure | E1 grade wood-based particleboard core with 0.8mm wood veneer finish | |
|---|---|---|
| Door panels | Solid wood framed raised arched panels with reddish brown lacquer | |
| Back panel | Hardboard fibreboard with matching wood grain finish | |
| Shelf panels | 25mm thick veneered wood-based panel with edge banding | |
| Surface finish | High-gloss scratch-resistant polyester lacquer in reddish walnut tone | |
| Hardware components | Zinc alloy combination lock, brass key lock, steel concealed hinges |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Secured left storage | Full-height hinged door with 3-dial combination lock for private document storage | |
|---|---|---|
| Right open display zone | Three tiered open shelves for book display and decorative item placement | |
| Secured lower right storage | Arched hinged door with key lock for lower secure storage of office supplies | |
| Adjustable shelf positions | Shelf pin holes allow 32mm incremental height adjustment for internal shelves |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office storage | Installed behind executive desks for document storage and decor display | |
|---|---|---|
| Reception area display storage | Used in formal reception zones to hold company materials and decorative items |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Applicable safety and strength requirements for domestic and office storage units | |
|---|---|---|
| EN 13986:2004+A1:2015 | Applicable specification for wood-based panels for structural furniture use |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.9 Storage Units |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable general technical requirements for wooden office furniture | |
|---|---|---|
| GB 18580-2017 | Applicable formaldehyde emission limit for wood-based panel products | |
| GB/T 4897.3-2003 | Applicable specification for particleboard used in furniture construction |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable general technical requirements for wooden office furniture; 2. GB 18580-2017: Applicable formaldehyde emission limit for wood-based panel products; 3. GB/T 4897.3-2003: Applicable specification for particleboard used in furniture construction; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
