Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 1350 x 400 x 2000 mm | |
|---|---|---|
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Per shelf static load capacity | 30 kg | |
|---|---|---|
| Net weight | 85 kg | |
| Door lock durability | 10000 lock cycles | |
| Hinge open/close cycle rating | 50000 cycles | |
| Anti-tip anchoring load rating | 100 kg | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Cabinet frame and panels | E1 grade medium density fiberboard with 0.6mm walnut wood veneer, stained reddish-brown finish | |
|---|---|---|
| Upper door panels | 5mm clear tempered glass set in solid wood door frames | |
| Lower door panels | 18mm wood veneer MDF with raised panel edge molding | |
| Hardware handles | Brushed nickel plated zinc alloy vertical pull handles | |
| Door hinges | Cold-rolled steel concealed cabinet hinges with soft close | |
| Lower door locks | Keyed alike brass core cam locks |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Upper storage function | Glass-fronted open display storage with adjustable shelves for books, awards and reference materials | |
|---|---|---|
| Lower storage function | Lockable solid-door concealed storage for confidential documents and office supplies | |
| Shelf adjustability | Upper shelves support 50mm incremental height adjustment via metal shelf pins | |
| Anti-tip protection | Wall anchor bracket included to secure cabinet to wall surfaces and prevent tipping |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office storage | Suited for placement behind executive desks to store reference books, awards and confidential files | |
|---|---|---|
| Meeting room reference storage | Suitable for meeting room back-of-house storage of meeting materials and display items |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Applicable standard for safety and strength requirements of domestic and office storage units | |
|---|---|---|
| EN 12150-1:2015 | Applicable standard for thermally toughened soda lime silicate safety glass in furniture |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.9 Storage Units |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable standard for general technical requirements of wooden furniture | |
|---|---|---|
| GB 18580-2017 | Applicable standard for formaldehyde emission limits for wood-based panels | |
| GB/T 4897.3-2015 | Applicable standard for particleboard used in furniture structural applications |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable standard for general technical requirements of wooden furniture; 2. GB 18580-2017: Applicable standard for formaldehyde emission limits for wood-based panels; 3. GB/T 4897.3-2015: Applicable standard for particleboard used in furniture structural applications; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
