| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 1200 x 400 x 2000 mm | |
|---|---|---|
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Single shelf static load capacity | 30 kg | |
|---|---|---|
| Product net weight | 85 kg | |
| Lower compartment storage volume per bay | 0.11 m³ | |
| Upper shelf document capacity per tier | 40 standard A4 binders | |
| Anti-tip load rating | 150 kg horizontal pull | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Cabinet carcass | 18 mm thick medium-density fiberboard with wood veneer finish | |
|---|---|---|
| Upper door panels | 5 mm clear tempered glass set in wood frames | |
| Lower door panels | 18 mm thick veneered engineered wood, solid wood edge banding | |
| Internal shelves | 25 mm thick veneered particleboard, edge-banded for wear resistance | |
| Hardware and handles | Brushed zinc alloy pull handles, steel lock cores, steel butt hinges | |
| Back panel | 5 mm thick hardboard, fixed to rear carcass for structural rigidity |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Door lock system | Centralized three-point lock securing all six doors, two keys included | |
|---|---|---|
| Upper storage function | Display and easy-access storage for frequently referenced documents, glass panels prevent dust accumulation | |
| Lower storage function | Concealed enclosed storage for archival materials and office supplies, solid doors block visual clutter | |
| Wall anchoring provision | Pre-drilled anti-tip bracket mounting points at rear top corners |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office application | Placed behind executive desks for document storage and professional aesthetic alignment with wood office furniture | |
|---|---|---|
| General office archival use | Used in open offices or administrative areas to store files, binders, and office supplies with mixed visible and concealed storage |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.9 Storage Units |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
