Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| overall dimensions | 800 x 400 x 2000 mm | |
|---|---|---|
| upper glass section height | 1250 mm | |
| lower solid door section height | 650 mm | |
| upper display shelf count | 3 | |
| upper shelf vertical spacing | 380 mm | |
| lower concealed shelf count | 1 | |
| lower compartment vertical spacing | 570 mm | |
| shelf thickness | 25 mm | |
| carcass side panel thickness | 18 mm | |
| back panel thickness | 9 mm | |
| upper glass panel thickness | 5 mm | |
| door handle length | 120 mm | |
| base plinth height | 80 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| unit net weight | 80 kg | |
|---|---|---|
| upper display shelf static load capacity | 15 kg per shelf | |
| hinge open/close cycle rating | 50000 cycles | |
| recommended maximum total stored load | 100 kg | |
| standard product warranty | 1 year | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| carcass and door construction | High-density fiberboard core with solid wood veneer, reddish-brown lacquer finish | |
|---|---|---|
| upper door panels | Clear tempered glass set in solid wood door frames | |
| lower door panels | Raised solid wood veneer panels with framed edge detailing | |
| hardware handles | Polished chrome-finished zinc alloy vertical bar pulls | |
| door hinges | Cold-rolled steel concealed hinges with 110-degree opening angle | |
| edge banding | 1 mm thick PVC edge banding matching wood finish on all exposed panel edges |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| door operation | Four hinged swing doors (two upper glass, two lower solid) opening outward for full interior access | |
|---|---|---|
| shelf adjustability | Upper shelves adjustable on 32 mm pitch metal support holes for variable storage heights | |
| stability feature | Included anti-tip wall anchor kit secures unit to wall to prevent tipping per furniture safety standards | |
| storage zoning | Upper glass-enclosed zone for display of decor, books and awards; lower solid-door zone for concealed document storage |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| executive office placement | Position against wall in private executive offices for book, document and award display and storage | |
|---|---|---|
| meeting room auxiliary storage | Used in formal meeting rooms to store reference materials and display corporate decor |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Domestic and kitchen storage units and worktops - safety requirements, applicable to stability and strength testing | |
|---|---|---|
| EN 12521:2015 | Furniture - strength, durability and safety for non-domestic storage furniture, applicable to commercial office use |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.9 Storage Units |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to dimensional and structural acceptance | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances for wood furniture, applicable to formaldehyde emission testing | |
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to structural panel material quality acceptance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to dimensional and structural acceptance; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances for wood furniture, applicable to formaldehyde emission testing; 3. GB/T 4897.3-2003: Particleboard for furniture use, applicable to structural panel material quality acceptance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
