Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 1200 x 420 x 2000 mm | |
|---|---|---|
| Upper display section height | 1320 mm | |
| Lower concealed storage section height | 680 mm | |
| Single door width | 380 mm | |
| Internal shelf depth (upper section) | 380 mm | |
| Adjustable shelf spacing (upper section) | 330 mm | |
| Lower storage compartment internal height | 620 mm | |
| Top panel thickness | 25 mm | |
| Carcass side panel thickness | 18 mm | |
| Shelf thickness | 30 mm | |
| Back panel thickness | 18 mm | |
| Tempered glass door panel thickness | 5 mm | |
| Plinth base height | 60 mm | |
| Metal pull handle length | 120 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Per-shelf static load capacity | 35 kg | |
|---|---|---|
| Lower compartment per-shelf static load | 45 kg | |
| Door hinge open angle | 110 degrees | |
| Hinge cycle rating | 80000 cycles | |
| Recommended maximum evenly distributed top load | 50 kg | |
| Warranty period | 5 years | |
| Available color option count | 5 | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Cabinet frame and panels | Walnut wood veneer over engineered wood core with UV cured paint finish | |
|---|---|---|
| Upper door panels | Clear tempered safety glass set in solid wood frames | |
| Lower door panels | Raised solid wood panels with framed edge detailing | |
| Door hardware | Polished zinc alloy vertical pull handles, concealed steel hinges | |
| Internal shelves | Solid wood edged adjustable shelves with metal support brackets | |
| Plinth base | Solid wood framed plinth sitting flush to floor |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Door operation | 6 hinged doors (3 upper glass, 3 lower solid) swing outward for full interior access | |
|---|---|---|
| Shelf adjustment | Upper section shelves adjust vertically on metal bracket supports | |
| Storage zoning | Upper zone provides visible display for books and decor, lower zone provides concealed storage for files | |
| Anti-tip security | 2 wall-mounted anti-tip connectors included to prevent forward tipping |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office use | Placed behind or beside executive desks for document storage and decorative display | |
|---|---|---|
| Conference room storage | Used to store reference materials and display awards along meeting room walls |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Office furniture storage furniture safety requirements for freestanding units | |
|---|---|---|
| EN 14074:2004 | Office furniture storage furniture test methods for structural durability |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.9 Storage Units |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to cabinet structural integrity | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture | |
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to core panel performance requirements |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to cabinet structural integrity; 2. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture; 3. GB/T 4897.3-2003: Particleboard for furniture use, applicable to core panel performance requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
