Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall assembled dimensions | 900 x 420 x 2000 mm | |
|---|---|---|
| Upper glass compartment height | 1200 mm | |
| Lower solid door compartment height | 800 mm | |
| Upper door glass panel dimensions per panel | 360 x 1080 mm | |
| Adjustable shelf count upper compartment | 3 | |
| Lower fixed shelf count | 1 | |
| Carcass side panel thickness | 25 mm | |
| Top and bottom trim thickness | 25 mm | |
| Door panel thickness | 18 mm | |
| Shelf panel thickness | 18 mm | |
| Edge banding thickness | 2 mm | |
| Metal pull handle length | 120 mm | |
| Adjustable shelf increment spacing | 32 mm | |
| Total interior storage height upper section | 1140 mm | |
| Total interior storage height lower section | 740 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Per shelf static load capacity upper section | 30 kg | |
|---|---|---|
| Total cabinet gross weight | 120 kg | |
| Hinge open angle per door | 110 degrees | |
| Hinge cycle rating | 80000 open/close cycles | |
| Keyed lock security | Keyed different lock with 2 included keys | |
| Scratch resistance of veneer finish | 2H pencil hardness | |
| Product warranty | 5 years | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Carcass core material | E1 grade MDF/particle board engineered wood | |
|---|---|---|
| Surface finish | Red-brown wood veneer with high-gloss lacquer coating | |
| Upper door panels | Clear tempered glass set in solid wood veneer frames | |
| Lower door panels | Engineered wood with matching wood veneer lacquer finish | |
| Hardware components | Zinc alloy vertical bar pulls, steel keyed lock, steel hinges | |
| Back panel | 8 mm thick hardboard with matching wood grain finish |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Upper compartment function | Open-swing glass door storage for books, awards and display items | |
|---|---|---|
| Lower compartment function | Lockable swing solid door storage for confidential documents and office supplies | |
| Shelf adjustability | Upper compartment shelves repositionable along pre-drilled holes at 32mm increments | |
| Installation type | Floor-standing freestanding unit with optional anti-tip wall anchor |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office application | Positioned behind executive desks for book, document and award display storage | |
|---|---|---|
| General office document storage | Used in open office areas or staff rooms for centralized document filing |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Applicable standard for office storage furniture safety and strength requirements | |
|---|---|---|
| EN 13986:2004+A1:2015 | Applicable standard for wood-based panel formaldehyde emission classification |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Applicable standard for office storage units performance and safety | |
|---|---|---|
| ANSI/BIFMA e3-2019e | Applicable standard for furniture sustainability and chemical emissions |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable standard for general technical requirements of wooden furniture | |
|---|---|---|
| GB 18580-2017 | Applicable standard for formaldehyde emission limits for wood-based panels | |
| GB/T 4893.4-2013 | Applicable standard for surface abrasion resistance testing of furniture finishes | |
| GB/T 10357.5-2011 | Applicable standard for furniture strength and durability testing for storage units |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable standard for general technical requirements of wooden furniture; 2. GB 18580-2017: Applicable standard for formaldehyde emission limits for wood-based panels; 3. GB/T 4893.4-2013: Applicable standard for surface abrasion resistance testing of furniture finishes; 4. GB/T 10357.5-2011: Applicable standard for furniture strength and durability testing for storage units; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
