Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall cabinet dimensions | 1200 x 400 x 2000 mm | |
|---|---|---|
| Left full-height solid door section width | 400 mm | |
| Upper glass door section height | 1200 mm | |
| Lower solid door section height | 600 mm | |
| Individual shelf clear spacing | 330 mm | |
| Shelf depth | 370 mm | |
| Glass door panel thickness | 5 mm | |
| Carcass panel thickness | 25 mm | |
| Back panel thickness | 5 mm | |
| Edge banding thickness | 2 mm | |
| Plinth base height | 100 mm | |
| Door handle length | 120 mm | |
| Adjustable shelf pin hole spacing | 32 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Per shelf static load capacity | 40 kg | |
|---|---|---|
| Door hinge open angle | 110 degrees | |
| Hinge cycle durability | 80000 cycles | |
| Product net weight | 120 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Warranty period | 5 years | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Carcass construction | E1 grade engineered wood with natural walnut wood veneer | |
|---|---|---|
| Display door panels | 5mm tempered clear glass with solid wood framed edging | |
| Hardware components | Brushed zinc alloy vertical pulls, keyed cam locks, steel hinges | |
| Surface finish | High-resistance PU lacquer with honey walnut stain | |
| Shelf material | 25mm thick veneered particle board with 2mm matching edge band | |
| Back panel | 5mm thick hardboard with wood grain finish |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Locking system | Keyed cam locks on left full-height door and lower storage section, 2 keys per lock | |
|---|---|---|
| Shelf adjustability | 6 adjustable shelves across glass display bays, pin-mounted height adjustment | |
| Door operation | Hinged swing doors with soft-close damping optional, flush recessed panel design | |
| Anti-tip safety | 2 wall anchor brackets included to secure cabinet to wall for fall prevention |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office private workspace | Provides secure document storage and display for awards and reference materials behind desk | |
|---|---|---|
| Open office administrative area | Stores shared files, office supplies and reference materials for department access |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Office storage furniture safety requirements for freestanding cabinets | |
|---|---|---|
| EN 14074:2004 | Office storage furniture test methods for structural strength and durability |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Storage furniture performance standard for office use, covering shelf load and structural stability |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural and finish quality acceptance | |
|---|---|---|
| GB 18584-2001 | Formaldehyde emission limit for wooden furniture, requires ≤1.5mg/L for indoor office use | |
| GB/T 4897.3-2003 | Particle board for furniture use, applicable to structural panel load performance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural and finish quality acceptance; 2. GB 18584-2001: Formaldehyde emission limit for wooden furniture, requires ≤1.5mg/L for indoor office use; 3. GB/T 4897.3-2003: Particle board for furniture use, applicable to structural panel load performance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
