Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 3600 x 420 x 2200 mm | |
|---|---|---|
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Single shelf maximum static load | 40 kg | |
|---|---|---|
| Total cabinet maximum static load | 320 kg | |
| Per drawer maximum static load | 25 kg | |
| Product net weight | 280 kg | |
| Design service life | 10 years | |
| Surface scratch resistance rating | 2B | |
| Adjustable shelf load support span | 800 mm | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Cabinet core panels | 18mm thick high-density particleboard core | |
|---|---|---|
| Exterior veneer | 0.6mm thick natural wood veneer with reddish-brown polished lacquer | |
| Decorative trim and carvings | Solid wood appliqués with raised relief design | |
| Door and drawer hardware | Zinc alloy pull handles with brushed silver finish and keyed cam locks | |
| Shelf panels | 25mm thick veneered engineered wood with edge banding | |
| Back panel | 9mm thick hardboard with matching wood veneer finish |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Storage configuration | Mixed open display shelves, lockable closed cabinets and central utility drawers | |
|---|---|---|
| Locking system | Keyed cam locks on all outer cabinet doors for secure document storage | |
| Shelf adjustability | Fixed shelf positions for upper open bays to support consistent display alignment | |
| Installation type | Freestanding floor-mounted unit with leveler feet on base plinth |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive private office placement | Positioned behind an executive desk for document storage and award display | |
|---|---|---|
| Boardroom ancillary storage | Installed along boardroom walls for reference material and decorative display |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety and performance requirements for domestic and office storage furniture | |
|---|---|---|
| EN 13722:2004 | Furniture - assessment of surface resistance to abrasion for wood finishes |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.9 Storage Units |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and structural quality checks | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of formaldehyde emission for wood furniture | |
| GB/T 4897.3-2003 | Specification for particleboard used in furniture structural applications |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and structural quality checks; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of formaldehyde emission for wood furniture; 3. GB/T 4897.3-2003: Specification for particleboard used in furniture structural applications; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
