Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 900 x 450 x 2000 mm | |
|---|---|---|
| Upper glass door section height | 1350 mm | |
| Lower solid door section height | 650 mm | |
| Individual door width | 430 mm | |
| Upper adjustable shelf count | 2 | |
| Upper shelf vertical spacing | 420 mm | |
| Lower storage compartment height | 590 mm | |
| Base plinth height | 60 mm | |
| Glass panel thickness | 5 mm | |
| Main carcass panel thickness | 25 mm | |
| Adjustable shelf thickness | 18 mm | |
| Back panel thickness | 5 mm | |
| Edge band thickness | 2 mm | |
| Internal usable depth | 410 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Single shelf static load capacity | 25 kg | |
|---|---|---|
| Hinge open/close cycle rating | 80000 cycles | |
| Door hinge opening angle | 110 degrees | |
| Surface scratch resistance | 2000 revolutions | |
| Product net weight | 65 kg | |
| Anti-tip anchor quantity | 2 | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Carcass and door panels | E1 grade MDF core with cherry wood veneer, lacquered finish | |
|---|---|---|
| Upper door panels | 5mm clear tempered glass set in solid wood veneer frames | |
| Door hardware | Brushed aluminum alloy vertical pull handles, steel cam lock | |
| Shelf supports | Zinc-plated steel shelf pins with 32mm system hole spacing | |
| Edge treatment | 2mm PVC edge banding on all exposed panel edges | |
| Back panel | 5mm hardboard fitted into routed panel grooves |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Upper storage | Glass-fronted hinged doors with 2 adjustable shelves for open book and decor display | |
|---|---|---|
| Lower storage | Lockable hinged solid doors with 1 fixed/removable shelf for concealed archive storage | |
| Shelf adjustment | 32mm spaced system holes allow 52mm incremental shelf height adjustment | |
| Door operation | Four independent hinged doors with full-length vertical pull handles for easy access |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office background storage | Positioned behind executive desks to store reference books, files and decorative display pieces | |
|---|---|---|
| Open office document zone | Used in shared office areas to organize archived documents and frequently accessed reference materials |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Office furniture - Storage furniture - Safety requirements, applicable for structural stability | |
|---|---|---|
| EN 14074:2004 | Office furniture - Storage furniture - Test methods for strength and durability |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Storage Furniture - Tests for durability, strength and stability, applicable for commercial use |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural and finish quality | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural and finish quality; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
