Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 1800 x 400 x 2000 mm | |
|---|---|---|
| Upper glass compartment height | 1200 mm | |
| Lower solid door compartment height | 800 mm | |
| Single column inner width | 530 mm | |
| Adjustable shelf count per upper column | 3 units | |
| Shelf spacing (adjustable max) | 350 mm | |
| Upper door glass thickness | 5 mm | |
| Main carcass panel thickness | 25 mm | |
| Back panel thickness | 9 mm | |
| Edge banding thickness | 2 mm | |
| Lower compartment internal shelf clearance | 720 mm | |
| Metal pull handle length | 120 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Single adjustable shelf static load capacity | 30 kg | |
|---|---|---|
| Lower door lock key differ count | 200 combinations | |
| Hinge open/close cycle rating | 80000 cycles | |
| Product net weight | 90 kg | |
| Finish scratch resistance | 2000 abrasion cycles | |
| Wall anti-tip connector static load | 50 kg | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Carcass panels | E1 grade high-density wood-based panel with reddish brown wood veneer | |
|---|---|---|
| Upper door panels | 5mm clear tempered glass set in solid wood framed borders | |
| Lower door panels | 25mm wood veneer panel with raised molded frame design | |
| Door hardware | Polished chrome-finish zinc alloy vertical bar pulls and keyed cylinder locks | |
| Shelves | 25mm thick wood veneer laminated panels with metal support pins | |
| Surface finish | Scratch-resistant matte PU paint in traditional reddish brown |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Door operation | Swing-hinged doors with 110-degree opening angle for full compartment access | |
|---|---|---|
| Upper shelf adjustment | Shelf positions adjustable via pre-drilled pin holes for variable storage heights | |
| Lower compartment security | Keyed alike cylinder locks on all 3 lower doors to secure sensitive documents | |
| Anti-tip protection | Included wall anchor hardware secures cabinet to wall to prevent forward tipping |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Carton dimensions | 1880 x 460 x 160 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office | Fits behind executive desks for document storage and displayed awards | |
|---|---|---|
| Government/enterprise archive areas | Provides locked lower storage for confidential files and open upper reference access |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Applicable for safety requirements of office storage furniture | |
|---|---|---|
| EN 14074:2004 | Applicable for test methods for office storage furniture strength and durability |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.9 Storage Units |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable for general technical requirements of wooden office furniture | |
|---|---|---|
| GB 18580-2017 | Applicable for formaldehyde emission limits of wood-based panel products | |
| GB/T 4897.3-2003 | Applicable for performance requirements of particleboard for furniture use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable for general technical requirements of wooden office furniture; 2. GB 18580-2017: Applicable for formaldehyde emission limits of wood-based panel products; 3. GB/T 4897.3-2003: Applicable for performance requirements of particleboard for furniture use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
