PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	1350 × 420 × 2000 mm
Overall assembled dimensions	1350 x 420 x 2000 mm
Left full-height solid door section width	450 mm
Right two bays upper glass door zone height	1300 mm
Right two bays lower solid door zone height	700 mm
Display shelf vertical spacing (glass section)	330 mm
Tempered glass door thickness	5 mm
Carcass main panel thickness	18 mm
Back panel thickness	5 mm
Shelf depth (adjustable display shelves)	380 mm
Door vertical pull handle length	120 mm
Solid door raised panel trim width	30 mm
Plinth base height	80 mm
Lower solid door internal shelf spacing	620 mm
Door overlay on carcass face frame	15 mm
Carcass Panel Thickness	25 mm
Door / Drawer Front Thickness	22 mm
Shelf Thickness	25 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Adjustable display shelf static load capacity	25 kg
Product net weight	120 kg
Door hinge open angle	110 degrees
Hinge cycle rating	80000 open/close cycles
Leveling foot adjustment range	15 mm
Shelf Distributed Load	30 kg/shelf
Drawer Slide Load / Life	45 kg/pair; 50000 cycles
Hinge Opening Angle / Life	165°; 80000 cycles
Anti-tip Fixing Reference	Products above 1200 mm should use at least 2 wall fixing points
Recommended Procurement Warranty	Carcass 5 years; hardware 3 years; finish 2 years

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Carcass and door substrates	E0-grade particleboard core with 0.6mm reddish brown wood veneer
Upper display door panels	5mm clear tempered safety glass framed in matching wood
Door hardware	Brushed zinc alloy vertical bar pulls, steel concealed hinges
Edge banding	1mm thick matching PVC edge banding on all exposed panel edges
Adjustable shelves	18mm thick veneered particleboard with metal shelf pins
Back panel	5mm thick hardboard with dark matte finish

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Display storage zone	Two upper glass-fronted bays with three adjustable shelves each for books and decor
Concealed storage zone	One full-height left solid door bay, two lower solid door bays for hidden document storage
Anti-tip protection	Two wall anchor straps included to secure cabinet to wall studs
Shelf adjustability	Shelf pins fit 32mm system holes for 32mm height increments on all internal shelves

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	2100× 700× 350 mm/carton according to carcass split
Reference Packaged Gross Weight	100 kg/set in 3 cartons

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Executive office space	Suitable for placement behind executive desks to store documents, awards and reference books
Conference room ancillary storage	Ideal for displaying meeting materials, corporate decor and storing office supplies

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 14749:2016	Safety and performance requirements for domestic and office storage furniture, applicable for structural safety
EN 12150-1:2015	Thermally toughened soda lime silicate safety glass for glass door panels, applicable for glazing safety

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

North America procurement and testing reference	ANSI/BIFMA X5.9 Storage Units

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017	General technical requirements for wooden furniture, applicable for structural and finish qualityAcceptance
GB 18580-2017	Formaldehyde emission limits for wood-based panels, applicable for E0-grade substrate compliance
GB/T 10357.5-2011	Furniture mechanical performance test for storage units, applicable for shelf load verification

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural and finish qualityAcceptance;
2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable for E0-grade substrate compliance;
3. GB/T 10357.5-2011: Furniture mechanical performance test for storage units, applicable for shelf load verification;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · BC-5D-RW-2000H

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · BC-5D-RW-2000H

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · BC-5D-RW-2000HOpen Export Tool

Quick Actions

Post an RFQ

Product Description

This traditional reddish brown 5-door wooden office display bookcase presents a balanced, classic silhouette suited for professional interior settings. Its freestanding layout dedicates a full-height solid door section to the left, paired with two adjacent right-side bays split horizontally between upper glass-fronted display space and lower solid-door concealed storage, creating a visually cohesive mixed-material facade with raised panel detailing that aligns with traditional design aesthetics. Built for lasting regular use, the cabinet uses an E0-grade particleboard core finished with 0.6mm reddish brown wood veneer across main carcass panels, with matching 1mm PVC edge banding on all exposed edges for a clean, finished look. The upper display doors are constructed from clear tempered safety glass framed in matching wood, fitted with brushed zinc alloy vertical bar pulls and steel concealed hinges that open to a wide accessible angle. All solid door panels match the veneered carcass finish, and adjustable shelves are made of thick veneered particleboard supported by metal shelf pins. The unit includes matching wood-framed glass doors for the upper zone, solid panel doors for concealed sections, and metal hardware throughout, with a dark matte hardboard back panel. Functionally, the bookcase delivers flexible dual-purpose storage. The two upper glass bays each hold three adjustable shelves, sized to display books, decorative items, awards or curated reference materials, with shelf positions adjustable in set increments via a standard 32mm hole system. The full-height left solid door bay and two lower right solid door bays provide enclosed, out-of-sight storage for documents, office supplies and less frequently accessed items. Two wall anchor straps are included for anti-tip security, and adjustable leveling feet accommodate uneven floor surfaces. Hinges and drawer slides are engineered for repeated long-term use, and shelves are rated to hold consistent distributed weight for regular storage needs. This bookcase is well suited for placement behind executive desks in private office spaces to hold reference materials, awards and working documents, and also works as ancillary storage in conference rooms to display corporate decor, meeting resources and stow shared supplies. It may also be used in residential home offices or traditional style studies where combined display and concealed storage is required. For procurement planning, note that the unit ships unassembled across multiple cartons, with a straightforward assembly process suitable for on-site setup. The freestanding design requires adequate wall clearance and access to wall studs for secure anti-tip installation, and its substantial net weight should be accounted for during delivery and placement.

Traditional Reddish Brown 5-Door Wooden Office Display Bookcase with Glass Upper Doors
