Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall cabinet dimensions | 900 x 400 x 2030 mm | |
|---|---|---|
| Upper glass door section height | 1400 mm | |
| Lower solid door storage section height | 630 mm | |
| Upper interior adjustable shelf count | 3 tiers | |
| Individual glass door panel size | 380 x 1320 mm | |
| Individual lower solid door panel size | 380 x 550 mm | |
| Clear glass thickness | 5 mm | |
| Cabinet side panel thickness | 25 mm | |
| Interior shelf panel thickness | 25 mm | |
| Back panel thickness | 9 mm | |
| Shelf vertical clearance (upper section) | 330 mm | |
| Edge banding thickness | 2 mm | |
| Plinth base height | 80 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Per shelf static load capacity | 30 kg | |
|---|---|---|
| Door hinge open angle | 110 degrees | |
| Hinge cycle durability | 80000 open/close cycles | |
| Product net weight | 75 kg | |
| Recommended wall fastener count for anti-tip | 2 units | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Cabinet frame and panels | Solid hardwood with warm walnut brown stain finish | |
|---|---|---|
| Upper door panels | Clear tempered glass set in wood frames | |
| Lower door panels | Raised solid wood panels with moulded frame edges | |
| Door pulls | Polished zinc alloy bar handles, 2 pairs total | |
| Interior backing | Dark finished wood composite backing panel | |
| Structural hardware | Zinc-plated steel three-in-one connecting fittings |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Upper glass door section | Enclosed display storage for books and decorative items, 3 tiered shelves | |
|---|---|---|
| Lower solid door section | Concealed closed storage for infrequently used items, single open compartment | |
| Shelf adjustability | Adjustable shelf positions via pre-drilled holes for variable item heights | |
| Anti-tip safety | Wall anchor installation required to prevent forward tipping |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Home study application | Suitable for home libraries and studies for book storage and decor display | |
|---|---|---|
| Office application | Suitable for executive offices and meeting rooms for document and award display |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Applicable for safety and strength requirements of domestic storage furniture |
|---|
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.9 Storage Units |
|---|
Standards applicable to China-market projects
| GB 18580-2017 | Applicable for formaldehyde emission limits of wood-based panel products | |
|---|---|---|
| GB/T 3324-2017 | Applicable for general technical requirements of wooden furniture | |
| GB/T 4897-2015 | Applicable for particleboard material performance if used in panels |
This product must meet the following technical requirements: 1. GB 18580-2017: Applicable for formaldehyde emission limits of wood-based panel products; 2. GB/T 3324-2017: Applicable for general technical requirements of wooden furniture; 3. GB/T 4897-2015: Applicable for particleboard material performance if used in panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
