Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Carcass Panel Thickness | 25 mm | |
|---|---|---|
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| shelf static load capacity | 30 kg | |
|---|---|---|
| unit net weight | 280 kg | |
| anti-tip wall anchor load rating | 100 kg | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| cabinet core material | 18mm thick high-density fiberboard | |
|---|---|---|
| exterior finish | 0.6mm mahogany wood veneer with high-gloss lacquer | |
| upper door panels | 5mm thick tempered clear glass | |
| hardware pulls | Polished zinc alloy bail handles | |
| shelf panels | 25mm thick veneer-covered engineered wood | |
| decorative trim | Carved solid wood appliques and fluted columns |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| storage configuration | Combination lockable glass display, open display, closed door storage and drawer storage | |
|---|---|---|
| lock function | Keyed locks on lower storage sections | |
| fixed shelf design | Non-adjustable fixed shelves across all compartments | |
| anti-tip safety feature | Wall anchor brackets included |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| shipping carton count | 6 cartons | |
|---|---|---|
| total shipping volume | 2.1 CBM | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| executive office space | Mounted as a wall unit behind an executive desk for document storage and decorative display, sized for large private offices | |
|---|---|---|
| conference room ancillary storage | Placed along a conference room wall for stored reference materials and decorative accents in high-end meeting spaces |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Applies to safety and strength requirements for domestic and office storage furniture | |
|---|---|---|
| EN 12521:2015 | Applies to strength, durability and stability requirements for office storage units |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.9 Storage Units |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | Applies to general technical requirements for wooden office furniture, for incoming quality inspection | |
|---|---|---|
| GB/T 4897.3-2003 | Applies to particleboard core material for furniture structural use | |
| GB 18584-2001 | Applies to formaldehyde emission limits for interior wooden furniture materials |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applies to general technical requirements for wooden office furniture, for incoming quality inspection; 2. GB/T 4897.3-2003: Applies to particleboard core material for furniture structural use; 3. GB 18584-2001: Applies to formaldehyde emission limits for interior wooden furniture materials; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
