| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 3600 x 420 x 2000 mm | |
|---|---|---|
| Handle length | 120 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Unit net weight | 285 kg | |
|---|---|---|
| Single shelf static load capacity | 30 kg | |
| Total storage volume | 2.12 m³ | |
| Recommended maximum loaded weight | 450 kg | |
| Adjustable shelf positions per compartment | 3 | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Frame and panel construction | 18mm medium density fiberboard core with 0.6mm solid wood veneer, glossy lacquer finish | |
|---|---|---|
| Upper side doors | 5mm clear tempered glass set in solid wood frames, framed by solid wood stiles and rails | |
| Hardware handles | Polished zinc alloy pull handles, brushed nickel finish, mounted on all doors and drawers | |
| Drawer slides | Cold-rolled steel side-mount drawer slides, 3/4 extension, zinc plated | |
| Door hinges | Concealed steel cabinet hinges with soft-close function, 100 degree opening angle | |
| Back panel | 9mm thick hardboard with black matte finish, fitted to rear of all display compartments |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Storage configuration | Six upper glass-enclosed display compartments, two open center display tiers, three center lower drawers, four lower solid-door storage cabinets | |
|---|---|---|
| Shelf adjustability | Upper glass compartment shelves support 3 height positions via pre-drilled pilot holes, no tools required for repositioning | |
| Door latching | All solid wood and glass doors include magnetic touch latches to hold closed position without visible strike plates | |
| Wall anchoring | Pre-drilled anti-tip bracket mounting points at top rear corners for secure attachment to load-bearing walls |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office spaces | Positioned behind an executive desk to store reference materials and display decorative awards or artifacts | |
|---|---|---|
| Boardroom ancillary storage | Installed along boardroom walls to hold meeting documents, presentation materials and display corporate decor |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.9 Storage Units |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
