Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall external dimensions | 900 x 400 x 2000 mm | |
|---|---|---|
| Upper glazed section height | 1330 mm | |
| Lower solid door section height | 670 mm | |
| Carcass panel thickness | 18 mm | |
| Top panel thickness | 25 mm | |
| Upper door glass panel thickness | 5 mm | |
| Internal upper shelf quantity | 3 pieces | |
| Shelf clear depth | 350 mm | |
| Shelf adjustable height increment | 32 mm | |
| Vertical metal pull handle length | 120 mm | |
| Door hinge opening angle | 110 degrees | |
| Back panel thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Single adjustable shelf static load capacity | 40 kg | |
|---|---|---|
| Hinge cycle durability | 80000 open/close cycles | |
| Product net weight | 121 kg | |
| Manufacturer warranty period | 5 years | |
| Available color variant count | 5 options | |
| Anti-tip wall anchor quantity | 2 pieces | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Carcass core material | E0 grade medium density fiberboard with wood veneer finish | |
|---|---|---|
| Upper door panels | Clear float glass set in solid wood framed edges | |
| Lower door panels | Raised wood-veneer MDF panels with framed edge detail | |
| Surface finish | Five-coat scratch-resistant polyurethane polish | |
| Hardware components | Zinc alloy vertical pull handles, steel hinges, central cam lock | |
| Edge banding | 2 mm thick PVC edge banding matching wood grain finish |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Door locking mechanism | Central keyed lock secures both upper and lower door pairs, supplied with 2 keys | |
|---|---|---|
| Shelf adjustment | Upper section shelves are height-adjustable via metal shelf pins at pre-drilled positions | |
| Door operation | Four hinged double doors (2 upper glass, 2 lower solid) open outward for full interior access | |
| Storage configuration | Upper open glazed zone for frequently accessed documents, lower enclosed zone for concealed archive storage |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Office document storage | Suitable for executive offices, administrative areas, and archive rooms for organized file storage | |
|---|---|---|
| Display and concealed storage | Upper glazed section displays frequently accessed materials, lower solid doors hide less used items |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Domestic and kitchen storage units and worktops, safety requirements for stability | |
|---|---|---|
| EN 312:2010 | Particleboard specifications, applicable for wood-based panel core performance | |
| EN 12521:2015 | Furniture for non-domestic use, storage units strength and durability requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Storage cabinets for office use, structural and durability performance standard |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural performance verification | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material formaldehyde emission limit for wood furniture, mandatory for indoor use | |
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable for core material quality verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural performance verification; 2. GB 18584-2001: Indoor decoration material formaldehyde emission limit for wood furniture, mandatory for indoor use; 3. GB/T 4897.3-2003: Particleboard for furniture use, applicable for core material quality verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
