Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 2400 x 1800 x 760 mm | |
|---|---|---|
| Main work surface depth | 900 mm | |
| Side return extension length | 1800 mm | |
| Side return width | 600 mm | |
| Desktop panel thickness | 50 mm | |
| Edge band thickness | 2 mm | |
| Knee clearance height | 650 mm | |
| Knee clearance width | 1600 mm | |
| Modesty panel height | 600 mm | |
| Mobile pedestal dimensions | 600 x 500 x 600 mm | |
| Support leg wall thickness | 30 mm | |
| Cable grommet diameter | 60 mm | |
| Under-desk clearance height | 100 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 181 kg | |
|---|---|---|
| Drawer slide static load | 45 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Hinge cycle rating | 80000 cycles | |
| Finish abrasion resistance | 2000 cycles | |
| Net weight (assembled) | 135 kg | |
| Recommended user weight capacity | 150 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop surface | 0.6mm red wood veneer over high-density fiberboard core | |
|---|---|---|
| Edge trim | Solid hardwood beveled edge, sealed with polyurethane clear coat | |
| Modesty panel and side panels | 18mm thick engineered wood with matching red wood veneer | |
| Support legs | Solid wood panel legs with integrated side support frames | |
| Hardware components | Zinc alloy drawer pulls and lock cylinders, cold-rolled steel drawer slides | |
| Mobile pedestal casters | 50mm diameter nylon swivel casters with brake locks |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Storage configuration | Lockable 3-drawer mobile pedestal under side return for file and office supply storage | |
|---|---|---|
| Cable management | 2 recessed cable grommets on desktop with under-desk cable tray for wire routing | |
| Modesty panel coverage | Full-height front modesty panel conceals seated leg area for office privacy | |
| Mobility feature | Return pedestal fitted with 4 lockable swivel casters for repositioning under the desk |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Primary application | Private executive offices in corporate, government, or institutional settings | |
|---|---|---|
| Usage mode | Supports desktop computing, document signing, and in-desk guest meetings across L-shaped surface |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables - Part 1: Dimensions, applicable for work surface and clearance size validation | |
|---|---|---|
| EN 527-2:2016 | Office work tables - Part 2: Mechanical safety requirements, applicable for structural stability and load testing | |
| EN 13722:2004 | Furniture - Strength and durability of storage units, applicable for pedestal drawer performance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products - Tests for performance and durability, applicable for structural load and cycle testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage Units - Tests for performance, applicable for mobile pedestal and drawer performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and structural qualityAcceptance inspection | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable for engineered wood core material performance | |
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture, applicable for formaldehyde emissionAcceptance inspection |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and structural qualityAcceptance inspection; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable for engineered wood core material performance; 3. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture, applicable for formaldehyde emissionAcceptance inspection; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
