| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall main desk dimensions | 2200 x 1100 x 760 mm | |
|---|---|---|
| Mobile side return cabinet dimensions | 1200 x 550 x 660 mm | |
| Integrated mobile pedestal dimensions | 490 x 420 x 660 mm | |
| Desktop thickness | 80 mm | |
| Seated knee clearance height | 580 mm | |
| Seated knee clearance width | 520 mm | |
| Base plinth height | 80 mm | |
| Wood veneer thickness | 0.6 mm | |
| Solid wood edge banding thickness | 8 mm | |
| Cable grommet diameter | 60 mm | |
| Back storage bookcase set dimensions | 3600 x 450 x 2000 mm | |
| Pedestal caster diameter | 50 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 200 kg | |
|---|---|---|
| Drawer slide load rating | 45 kg | |
| Drawer slide cycle durability | 50000 cycles | |
| Door hinge cycle durability | 80000 cycles | |
| Surface scratch resistance | 3H | |
| Formaldehyde emission level | 0.05 mg/m³ | |
| Net weight reference | 200 kg | |
| Warranty period | 10 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desk substrate | E0 grade high-density fiberboard with solid wood framing | |
|---|---|---|
| Surface finish | Red-brown environmental PU paint with multi-layer polished coating | |
| Desktop inlay | Black embossed leather writing pad surface | |
| Edge construction | Solid hardwood edge banding with seamless paint finish | |
| Drawer hardware | Zinc alloy drawer pulls and central lock cylinders | |
| Mobility components | 50mm diameter nylon silent swivel casters on side return |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Storage configuration | Central drawer stack on main desk, open storage and lockable compartments on side return | |
|---|---|---|
| Cable management | Dual desktop cable grommets connected to under-desk cable tray | |
| Side cabinet mobility | Mobile side return fitted with lockable casters for flexible positioning | |
| Drawer security | Central locking system secures all desk drawers with included keys |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive private office | Suitable for senior management private offices, providing formal professional workspace | |
|---|---|---|
| Matching suite configuration | Designed to pair with matching leather executive chair and wood bookcase set |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applicable to safety and dimensional requirements for office work desks | |
|---|---|---|
| EN 13722:2004 | Applicable to strength and durability requirements for office storage furniture |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applicable to performance testing standard for desk products |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable to general technical requirements for wooden office furniture | |
|---|---|---|
| GB 18584-2001 | Applicable to formaldehyde emission limits for wooden interior furniture | |
| GB/T 4897.3-2003 | Applicable to performance requirements for wood-based panel substrates |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable to general technical requirements for wooden office furniture; 2. GB 18584-2001: Applicable to formaldehyde emission limits for wooden interior furniture; 3. GB/T 4897.3-2003: Applicable to performance requirements for wood-based panel substrates; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
