Traditional Double-Pedestal Mahogany-Finish Executive Desk with Inset Writing Pad (model ED-DP-1800-REDWD) is listed under Traditional Manager Desk, with overall dimensions of 1800 × 900 × 760 mm and main material of MDF. Load capacity: 100 kg. Certifications: traditional,formal,style,double,pedestal,base,knee,opening,panel,fronts. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall desk dimensions | 1800 x 900 x 760 mm | |
|---|---|---|
| Desk top thickness | 38 mm | |
| Wood veneer thickness | 0.8 mm | |
| Solid wood edge band thickness | 2 mm | |
| Central knee clearance height | 660 mm | |
| Central knee clearance width | 600 mm | |
| Knee clearance depth | 500 mm | |
| Inset writing pad dimensions | 800 x 400 mm | |
| Plinth base height | 80 mm | |
| Decorative stud panel size | 300 x 120 mm | |
| Cable grommet diameter | 60 mm | |
| Drawer internal depth (file drawers) | 450 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desk net weight | 154 kg | |
|---|---|---|
| Desktop static load capacity | 100 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Door/drawer hinge cycle rating | 80000 cycles | |
| Surface abrasion resistance | 2000 cycles | |
| Recommended user weight capacity | 136 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desk substrate | E1-grade MDF, density 800 kg/m³, moisture content 10% | |
|---|---|---|
| Surface finish | 8-coat polyester paint, reddish mahogany wood grain | |
| Work surface inlay | Dark smooth writing pad, matte finish | |
| Pedestal construction | Panel-constructed wood case, enclosed storage with solid plinth base | |
| Hardware components | Brass-finish metal decorative studs, ball-bearing drawer slides, core-removable locks | |
| Edge treatment | Solid wood edge banding, rounded molded overhang profile |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Storage configuration | 7 drawers across double pedestals, including 2 locking file drawers and 5 utility drawers | |
|---|---|---|
| Cable management | 2 desktop cable grommets routed to under-desk cable tray | |
| Leveling adjustment | Integrated floor glides at plinth base to adjust for uneven floor surfaces | |
| Drawer operation | Full-extension ball-bearing slides, core-removable central lock for security |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive private office | Formal traditional styling suitable for senior management and director workspaces | |
|---|---|---|
| Government/state-owned enterprise office | Classic red wood finish matches formal institutional office design standards |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables - Part 1: Dimensions, applicable to desk height and clearance requirements | |
|---|---|---|
| EN 527-2:2002+A1:2019 | Office work tables - Part 2: Mechanical safety requirements and test methods | |
| EN 13722:2004 | Furniture - Strength, durability and stability for office storage units |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products - Performance standard for structural safety and durability of office desks | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage Units - Performance standard for pedestal drawer and cabinet components |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk structural performance | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of formaldehyde emission for wooden furniture | |
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to substrate quality verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk structural performance; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of formaldehyde emission for wooden furniture; 3. GB/T 4897.3-2003: Particleboard for furniture use, applicable to substrate quality verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
