Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall external dimensions | 800 x 400 x 850 mm | |
|---|---|---|
| Raised back gallery splash height | 80 mm | |
| Upper glass door compartment clear opening height | 380 mm | |
| Upper compartment clear opening width per door | 360 mm | |
| Adjustable interior shelf thickness (per compartment) | 15 mm | |
| Lower drawer face height per drawer | 180 mm | |
| Lower drawer internal usable depth | 360 mm | |
| Cabinet carcass side panel thickness | 18 mm | |
| Back panel thickness | 16 mm | |
| Solid wood edge banding thickness | 6 mm | |
| Tempered glass door panel thickness | 5 mm | |
| Round hardware knob diameter | 50 mm | |
| Plinth base height | 60 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Top surface uniform static load capacity | 50 kg | |
|---|---|---|
| Adjustable interior shelf uniform static load | 15 kg | |
| Lower drawer maximum static load per drawer | 10 kg | |
| Total cabinet net weight | 45 kg | |
| Formaldehyde emission rating (substrate) | 0.05 mg/m³ | |
| Paint surface pencil hardness | 2H | |
| Solid wood component moisture content | 12% | |
| Drawer slide open/close cycle durability | 50000 cycles | |
| Door hinge open/close cycle durability | 80000 cycles | |
| Shelf Distributed Load | 30 kg/shelf |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Cabinet carcass substrate | E1 grade MDF core with wood veneer overlay | |
|---|---|---|
| Upper door panels | Clear tempered glass set in solid wood frames | |
| Hardware knobs | Polished chrome-plated zinc alloy round pulls | |
| Finish coating | Scratch-resistant water-based polyurethane wood finish | |
| Edge trim | Solid wood inlay accent lines across all front panels | |
| Drawer slides and hinges | Cold-rolled steel with anti-rust zinc plating |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Upper storage access | Two hinged arched glass doors with one adjustable shelf per compartment | |
|---|---|---|
| Lower storage access | Two full-depth equal-width drawers for closed accessory storage | |
| Item fall protection | Curved raised gallery edge along back and sides of top surface | |
| Wall stabilization | Pre-drilled anti-tip hardware mounting points on rear carcass |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Office meeting room use | Positioned against wall for tea ware, cup and beverage accessory storage | |
|---|---|---|
| Executive office side storage | Placed adjacent to executive desk for refreshment and document accessory storage |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Domestic and kitchen storage units and worktops - safety and performance requirements | |
|---|---|---|
| EN 12521:2015 | Furniture - strength, durability and safety requirements for domestic tables |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to dimensional and structural acceptance | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of formaldehyde emission for wooden furniture | |
| GB/T 4893.4-2013 | Surface wear resistance test method for furniture coatings, applicable to finish durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to dimensional and structural acceptance; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of formaldehyde emission for wooden furniture; 3. GB/T 4893.4-2013: Surface wear resistance test method for furniture coatings, applicable to finish durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
