Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 1800 x 450 x 920 mm | |
|---|---|---|
| Backsplash height | 50 mm | |
| Plinth base height | 100 mm | |
| Solid side door dimensions | 420 x 600 mm | |
| Central glass door dimensions | 300 x 600 mm per door | |
| Central drawer dimensions | 960 x 150 mm | |
| Drawer internal depth | 400 mm | |
| Adjustable shelf spacing | 280 mm | |
| Glass panel thickness | 5 mm | |
| Door panel thickness | 25 mm | |
| Top surface thickness | 30 mm | |
| Back panel thickness | 9 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Top surface static load capacity | 80 kg | |
|---|---|---|
| Hinge open angle | 110 degrees | |
| Hinge cycle rating | 80000 open/close cycles | |
| Drawer slide load rating | 25 kg | |
| Drawer slide cycle rating | 50000 open/close cycles | |
| Product net weight | 90 kg | |
| Anti-tip restraint included per safety norms | 2 wall anchors | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Carcass and door frames | Kiln-dried solid hardwood with reddish-brown lacquer finish | |
|---|---|---|
| Central door panels | Clear tempered glass with horizontal wood muntin divider | |
| Hardware pulls and handles | Polished chrome-finish zinc alloy curved pulls | |
| Back panel | Engineered wood hardboard backing | |
| Edge banding | 0.6 mm solid wood edge matching carcass finish | |
| Adjustable shelves | 18 mm thick solid wood/veneer core shelves |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Door operation | Four swing-open hinged doors (two solid, two glass) for enclosed storage | |
|---|---|---|
| Drawer function | One full-width lower central drawer on side-mount slides for small item storage | |
| Shelf adjustability | Multi-position adjustable shelves in each cabinet compartment | |
| Surface protection | Raised rear backsplash lip prevents spills from falling behind unit |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Dining room buffet use | Placed along dining walls for tableware, linens and serving piece storage | |
|---|---|---|
| Pantry/tea room storage | Used for tea sets, dry goods and small kitchen appliance storage |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Domestic and kitchen storage units and worktops, safety and performance requirements | |
|---|---|---|
| EN 12521:2015 | Furniture for domestic use, seating and tables strength/durability applicable for top load |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for carcass and finish quality | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture, formaldehyde emission requirement |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for carcass and finish quality; 2. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture, formaldehyde emission requirement; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
